A740G3L BIOS Manual
29
CPU Tuning
BIOS SETUP UTILITY
vxx.xx (C)Copyright 1985-200x, American Megatrends, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
CPU Tuning
Hyper Transfer Link Configuration
CPU/HT Reference Clock (MHZ) [200]
CPU Over Voltage [StartUp]
Custom P-States [Disabled]
HT Link Speed : [Auto]
HT Link Width : [Auto]
Core Leveling [Auto]
SVID Override [Disabled]
Performance
Allows BIOS to Select
CPU Over Clock.
CPU/HT Reference range
200MHz - 600MHz
CPU/HT Reference Clock (MHz)
This item allows BIOS to select CPU Over Clock.
Options: 200 (Default) / 200~600
CPU Over Voltage
This item allows you to change CPU voltage value.
Custom P-States
This item tells BIOS whether to use the setup options below this to configure the
P-States, or whether to configure the P-States automatically.
Options: Disabled (Default) / Enabled
Core FID
This item allows you to select the Ratio/Frequency of AM3 CPU.
Options: x8.0 1600MHz ~ x15.5 3100MHz (Differed by CPU)
Core VID
This function allows you to adjust the voltage of AM3 CPU.
Core DID
Options: Divided by 1 (Default) / Divided by 2 / Divided by 4 / Divided by 8 /
Divided by 16
