A740G3L BIOS Manual
25
UMA Frame Buffer Size
This item allows you to choose the UMA frame buffer size for internal graphics.
Options: Auto (Default) / 32MB / 64MB / 128MB / 256MB / 512MB / 1024MB
Graphics Clock Mode
This item allows you to set the mode of Graphics Clock.
Options: Sync (Default) / Async
Aync GFX Clock Speed
This item allows you to set Aync GFX Clock Speed.
Options: 133MHz (Default) / 166MHz / 200MHz / 266MHz / 300MHz / 333MHz /
400MHz / 533MHz / 633MHz
Multifunction
This item allows you to activate Multifunction.
Options: Disabled (Default) / Enabled
Surround View
This item allows you to control the Surround View Function.
Options: Disabled (Default)
Primary Video Controller
This option allows you to select the video controller in charge.
Options: PCIE/IGFX/PCI (Default) / PCI/PCIE/IGFX / IGFX/PCIE/PCI
PCI Express Configuration
BIOS SETUP UTILITY
Chipset
vxx.xx (C)Copyright 198 5-200x, American Megatre nds, Inc.
Select Screen
Select Item
Update
General Help
Save and Exit
Exit
Enter
F1
F10
ESC
PCI Express Config uration
PCIE GFX Overclock ing [Disabled]
NB-SB PCIE Link AS PM [Disabled]
GFX PCIE Link ASPM [Disabled]
GPP PCIE Link ASPM [Disabled]
GFX0 Slot Power Li mit, W [75 ]
GPP Slots Power Li mit, W [25 ]
PCIE GFX0 Link Wid th [Auto]
