Motherboard Manual
32
FRENCH
A785G3 A780L3/A780L3G
UC
Socket AM3
Processeurs AMD Phenom II/ Athlon II
L'architecture AMD 64 permet le calcul 32 et 64
bits
Prend en charge Hyper Transport 3.0 et
Cool’n’Quiet
(Watt maximum : 125W)
Socket AM3
Processeurs AMD Phenom II/ Athlon II
L'architecture AMD 64 permet le calcul 32 et 64
bits
Prend en charge Hyper Transport 3.0 et
Cool’n’Quiet
(Watt maximum : 125W)
Bus frontal
Prend en charge Hyper Transport 3.0 jusqu'à
une bande passante de 5.2 GT/s
Prend en charge Hyper Transport 3.0 jusqu'à
une bande passante de 5.2 GT/s
Chipset
AMD 785G
AMD SB710
AMD 780L
AMD SB710
Super E/S
ITE 8718F
Fournit la fonctionnalité de Super E/S
patrimoniales la plus utilisée.
Interface à f aib le co mpte de b roches
Initiatives de contrôle environnementales,
Moniteur d e mat ér iel
Fonction "Gardien intelligent" de l'ITE
ITE 8718F
Fournit la fonctionnalité de Super E/S
patrimoniales la plus utilisée.
Interface à f aib le co mpte de b roches
Initiatives de contrôle environnementales,
Moniteur d e mat ér iel
Fonction "Gardien intelligent" de l'ITE
Mémoire
principale
Fentes DDR3 DIMM x 2
Capacité mémo ire max imale de 8 Go
Chaque DIMM prend en charge des DDR3 de
256 Mo/512 Mo et 1Go/2Go/4Go
Module de mémoire DDR3 à mode à double voie
Prend en charge la DDR3 800 / 1066 / 1333
Les DIMM à registres et DIMM avec code
correcteurs d'erreurs ne sont pas prises en
charge
Fentes DDR3 DIMM x 2
Capacité mémo ire max imale de 8 Go
Chaque DIMM prend en charge des DDR3 de
256 Mo/512 Mo et 1Go/2Go/4Go
Module de mémoire DDR3 à mode à double voie
Prend en charge la DDR3 800 / 1066 / 1333
Les DIMM à registres et DIMM avec code
correcteurs d'erreurs ne sont pas prises en
charge
Graphiques
Integré dans la chipset AMD 785G
Mémoire vidéo partagée max imale de 512 Mo
Prise en charge DX10.1/HDCP/UVD2
Integré dans la chipset AMD 780L
Mémoire vidéo partagée max imale de 512 Mo
Prise en charge DX10/HDCP
IDE
Contrôleur IDE intégré
Mode principale de Bus Ultra DMA 33 / 66 / 100
/ 133
Prend en charge le mode PIO 0~4,
Contrôleur IDE intégré
Mode principale de Bus Ultra DMA 33 / 66 / 100
/ 133
Prend en charge le mode PIO 0~4,
SATA
Contrôleur Serial ATA
int égré
Taux de transfert jusqu'à 3 Go/s.
Conforme à la spécificat ion SATA Vers ion 2.0
Contrôleur Serial ATA
int égré
Taux de transfert jusqu'à 3 Go/s.
Conforme à la spécificat ion SATA Vers ion 2.0
LAN
Realtek RTL 8111DL
10 / 100 / 1000 Mb/s négociation automatique
Half / Full duplex capability
Realtek RTL 8102EL / RTL 8111DL
10 / 100 Mb/s négociation automatique
(A780L3)
10 / 100 / 1000 Mb/s négociation automatique
(A780L3G)
Half / Full duplex capability
