A785G3/A780L3/A780L3G
33
A785G3 A780L3/A780L3G
Prise en
charge
audio HD
ALC662
Sortie aud io à 5 .1 vo ies
Prise en charg e de l'audio haute définition
ALC662
Sortie aud io à 5 .1 vo ies
Prise en charg e de l'audio haute définition
Fente PCI Express Gen2 x16 x1 Fente PCI Express Gen2 x16 x1
Fentes
Fente PCI x2 Fente PCI x2
Connecteur de disquette x1 Connecteur de disquette x1
Connecteur IDE x1 Connecteur IDE x1
Connecteur SATA x4 Connecteur SATA x4
Connecteur du panneau avant x1 Connecteur du panneau avant x1
Connecteur Audio du panneau avant x1 Connecteur Audio du panneau avant x1
Connecteur de sortie S/PDIF x1 Connecteur de sortie S/PDIF x1
Embase de ventilateur UC x1 Embase de ventilateur UC x1
Embase de ventilateur système x1 Embase de ventilateur système x1
Embase d'effacement CMOS x1 Embase d'effacement CMOS x1
Connecteur USB x2 Connecteur USB x2
Connecteur d'alimentation x1
(24 broches)
Connecteur d'alimentation x1
(24 broches)
Connecteur d'alimentation x1
(4 broch es)
Connecteur d'alimentation x1
(4 broch es)
Connecteur de Port d'imprimante x1 Connecteur de Port d'imprimante x1
Connecteur
embarqué
Connecteur de Port série x1 Connecteur de Port série x1
E/S du
panneau
arrière
Clavier PS/2 x1
Souris PS/2 x1
Port VGA x1
Port LAN x1
Port USB x4
Fiche audio x3
Port DVI x1
Clavier PS/2 x1
Souris PS/2 x1
Port VGA x1
Port LAN x1
Port USB x4
Fiche audio x3
Port DVI x1
Dimension
s de la
cart e
200 mm (l) X 244 mm (H) 200 mm (l) X 244 mm (H)
Fonctionnal
ités
spéciales
Prise en charge RAID 0 / 1 / 1+0 Prise en charge RAID 0 / 1 / 1+0
Support SE
Windows XP / Vista / 7
Biostar se réserve le droit d'ajouter ou de
supprimer le support de SE avec ou sans
préavis.
Windows XP / Vista / 7
Biostar se réserve le droit d'ajouter ou de
supprimer le support de SE avec ou sans
préavis.
