Motherboard Manual
38
PORTUGUESE
A785G3 A780L3/A780L3G
CPU
Socket AM3
Processadores AMD Phenom II/ Athlon II
A arquitectura AMD 64 permite uma
computação de 32 e 64 bits
Suporta as tecno log ias Hyper Transport 3.0 e
Cool’n’Quiet
(Watt máximo: 125W)
Socket AM3
Processadores AMD Phenom II/ Athlon II
A arquitectura AMD 64 permite uma
computação de 32 e 64 bits
Suporta as tecno log ias Hyper Transport 3.0 e
Cool’n’Quiet
(Watt máximo: 125W)
FSB
Suporta a tecnologia HyperTransport 3.0 com
uma largura de banda até 5.2 GT/s
Suporta a tecnologia HyperTransport 3.0 com
uma largura de banda até 5.2 GT/s
Chipset
AMD 785G
AMD SB710
AMD 780L
AMD SB710
Especificaç
ão Super
I/O
ITE 8718F
Proporciona as funcionalidades mais utilizadas
em termos da especificação Super I/O.
Interface LPC (Low Pin Count).
In iciat ivas para contro lo do amb iente
Monitorização do hardware
Função "Smart Gu ardian" d a ITE
ITE 8718F
Proporciona as funcionalidades mais utilizadas
em termos da especificação Super I/O.
Interface LPC (Low Pin Count).
In iciat ivas para contro lo do amb iente
Monitorização do hardware
Função "Smart Gu ardian" d a ITE
Memória
principal
Ranhuras DIMM DDR3 x 2
Capacidad e máx ima d e memória: 8 GB
Cada módulo DIMM suporta uma memória
DDR3 de 512 MB & 1 GB/2 GB/4 GB
Módulo de memória DDR3 de canal duplo
Suporta módulos DDR3 800 / 1066 / 1333
Os módulos DIMM registados e os DIMM ECC
não são suportados
Ranhuras DIMM DDR3 x 2
Capacidad e máx ima d e memória: 8 GB
Cada módulo DIMM suporta uma memória
DDR3 de 512 MB & 1 GB/2 GB/4 GB
Módulo de memória DDR3 de canal duplo
Suporta módulos DDR3 800 / 1066 / 1333
Os módulos DIMM registados e os DIMM ECC
não são suportados
Placa
gráfica
Integrada no chipset AMD 785G
Memória de vídeo máxima partilhada: 512 MB
Suporta as funções DX10.1/HDCP/UVD2
Integrada no chipset AMD 780L
Memória de vídeo máxima partilhada: 512 MB
Suporta as funções DX10/HDCP
IDE
Controlador IDE integrado
Modo Bus master Ultra DMA 33 / 66 / 100 / 133
Suporta o modo PIO 0~4,
Controlador IDE integrado
Modo Bus master Ultra DMA 33 / 66 / 100 / 133
Suporta o modo PIO 0~4,
SATA
Controlador Serial ATA integrado
Velocidades de transmissão de dados até 3
Gb/s.
Compat ibilidade co m a especificação SATA
versão 2.0.
Controlador Serial ATA integrado
Velocidades de transmissão de dados até 3
Gb/s.
Compat ibilidade co m a especificação SATA
versão 2.0.
LAN
Realtek RTL 8111DL
Auto negociação de 10 / 100 / 1000 Mb/s
Capacidade semi/full-duplex
Realtek RTL 8102EL / RTL 8111DL
Auto negociação de 10 / 100 Mb/s (A780L3)
Auto negociação de 10 / 100 / 1000 Mb/s
(A780L3G)
Capacidade semi/full-duplex
