A785G3/A780L3/A780L3G
37
A785G3 A780L3/A780L3G
Soporte de
sonido HD
ALC662
Salida de sonido de 5.1 canales
Soporte de sonido Alta Definición
ALC662
Salida de sonido de 5.1 canales
Soporte de sonido Alta Definición
Ranura PCI Express Gen2 x16 X1 Ranura PCI Express Gen2 x16 X1
Ranuras
Ranura PCI X2 Ranura PCI X2
Conector disco flexible X1 Conector disco flexible X1
Conector IDE X1 Conector IDE X1
Conector SATA X4 Conector SATA X4
Conector de panel frontal X1 Conector de panel frontal X1
Conector de sonido frontal X1 Conector de sonido frontal X1
Conector de salida S/PDIF X1 Conector de salida S/PDIF X1
Cabecera de ventilador de CPU X1 Cabecera de ventilador de CPU X1
Cabecera de ventilador de sistema X1 Cabecera de ventilador de sistema X1
Cabecera de borrado de CMOS X1 Cabecera de borrado de CMOS X1
Conector USB X2 Conector USB X2
Conector de alimentación X1
(24 patillas)
Conector de alimentación X1
(24 patillas)
Conector de alimentación X1
(4 patillas)
Conector de alimentación X1
(4 patillas)
Conector Puerto de impresora X1 Conector Puerto de impresora X1
Conectores
en placa
Conector Puerto serie X1 Conector Puerto serie X1
Panel
trasero de
E/S
Tec lad o PS /2 X 1
Ratón PS/2 X1
Puerto VGA X1
Puerto de red local X1
Puerto USB X4
Conector de sonido X3
Puerto DV I X1
Tec lad o PS /2 X 1
Ratón PS/2 X1
Puerto VGA X1
Puerto de red local X1
Puerto USB X4
Conector de sonido X3
Puerto DV I X1
Ta mañ o d e
la placa
200 mm. (A) X 244 Mm. (H) 200 mm. (A) X 244 Mm. (H)
Funciones
especiales
Admite RAID 0 / 1 / 1+0 Admite RAID 0 / 1 / 1+0
Soporte de
sistema
operativo
Windows XP / Vista / 7
Biostar se reserva el derecho de añadir o retirar
el soporte de cualquier SO con o sin aviso previo.
Windows XP / Vista / 7
Biostar se reserva el derecho de añadir o retirar
el soporte de cualquier SO con o sin aviso previo.
