Motherboard Manual
50
ITALIAN
SPECIFICA
CPU
Socket AM3
Processori AMD Phenom II/ Athlon II
L’architettura AMD 64 abilita la computazione 32
e 64 bit
Supporto di Hyper Transport 3.0
FSB
Supporto di HyperTransport 3.0 fino a
5.2 GT/s di larghezza di banda
Chipset
AMD 790GX (TA790GXB3)
AMD 785G (TA785-A3)
AMD SB750 (TA790GXB3)
AMD SB710 (TA785-A3)
Super I/O
ITE 8718
Fornisce le funzionalità legacy Super
I/O usate più comunemente.
Interfaccia LPC (Low Pin Count)
Funzioni di controllo dell’ambiente:
Monitoraggio hardware
Controller velocità ventolina
Funzione "Smart Guardian" di ITE
Memoria
principale
Alloggi DIMM DDR3 x 4
Capacità massima della memoria 16GB
Ciascun DIMM supporta DDR3
512MB/1GB/2GB/4GB
Modulo di memoria DDR3 a canale doppio
Supporto di DDR3 800 / 1066 / 1333
Supporto di DDR3 1600 (OC)
DIMM registrati e DIMM ECC non sono supportati
Grafica
AMD 790GX (Radeon HD 3300)
AMD 785G (Radeon HD4200)
La memoria video condivisa massima è di 512 MB
Supporto DX10/UVD/HDCP
IDE
AMD SB750 (TA790GXB3)
AMD SB710 (TA785-A3)
Modalità Bus Master Ultra DMA 33 / 66 / 100 / 133
Supporto modalità PIO Mode 0-4
SATA II
AMD SB750 (TA790GXB3)
AMD SB710 (TA785-A3)
Velocità di trasferimento dei dati fino a 3 Gb/s.
Compatibile specifiche SATA Versione 2.0.
Supporto RAID 0,1,5,1+0
(RAID 5 per TA790GXB3 solo)
LAN
Realtek RTL 8111DL
Negoziazione automatica 10 / 100 / 1000 Mb/s
Capacità Half / Full Duplex
Codec
audio
ALC662
Uscita audio 5.1 canali
Supporto audio High-Definition (HD)
Alloggio PCI x3
Alloggio PCI Express Gen2 x16 x1
Alloggi
Alloggio PCI Express Gen2 x1 x2
