TA790GXB3/TA785-A3
55
ESPECIFICAÇÕES
Conector da unidade de disquetes x1 Cada conector suporta 2 unidades de disquetes
Conector da para impressora x1 Cada conector suporta 1 Porta para impressora
Conector IDE x1 Cada conector suporta 2 dispositivos IDE
Conector SATA x6 Cada conector suporta 1 dispositivo SATA
Conector do painel frontal x1 Para suporte de várias funções no painel frontal
Conector de áudio frontal x1 Suporta a função de áudio no painel frontal
Conector para entrada de CDs x1 Suporta a entrada de áudio a partir de CDs
Conector de saída S/PDIF x1 Suporta a saída de áudio digital
Conector da ventoinha da CPU x1
Alimentação da ventoinha da CPU (com a função Smart
Fan)
Conector da ventoinha do sistema x2 Alimentação da ventoinha do sistema
Conector para limpeza do CMOS x1
Conector USB x3 Cada conector suporta 2 portas USB no painel frontal
Conector da Porta série x1
Conector de alimentação x1
(24 pinos)
Conectores
na placa
Conector de alimentação x2
(4 pinos)
Entradas/S
aídas no
painel
traseiro
Tecl ado PS/2 x1
Rato PS/2 x1
Porta VGA x1
Porta DVI-D x1
Porta LAN x1
Porta USB x4
Tomada de áudio x3
Taman ho
da placa
225 mm (L) X 305 mm (A) ATX
Sistemas
operativos
suportados
Windows XP / Vista 32 / Vista 64
A Biostar reserva-se o direito de adicionar ou remover
suporte para qualquer sistema operativo com ou sem
aviso prévio.
