TA790GXB3/TA785-A3
59
СПЕЦ
Разъём НГМД x1
Каждый разъём поддерживает 2 накопителя на
гибких магнитных дисках
Разъём Порт подключения
принтера x1
Каждый разъём поддерживает 1 Порт
подключения принтера
Разъём IDE x1
Каждый разъём поддерживает 2 встроенных
интерфейса накопителей
Разъём SATA x6 Каждый разъём поддерживает 1 устройство SATA
Разъём на лицевой панели x1 Поддержка устройств на лицевой панели
Входной звуковой разъём x1
Поддержка звуковых функций на лицевой
панели
Разъём ввода для CD x1 Поддержка функции ввода для CD
Разъём вывода для S/PDIF x1 Поддержка вывода цифровой звуковой функции
Контактирующее приспособление
вентилятора центрального процессора x1
Источник питания для вентилятора центрального
процессора (с функцией интеллектуального
вентилятора)
Контактирующее приспособление
вентилятора системы x2
Источник питания для вентилятора системы
Открытое контактирующее
приспособление CMOS x1
USB-разъём x3
Каждый разъём поддерживает 2 USB-порта на
лицевой панели
Разъём Последовательный порт x1
Разъем питания (24 вывод) x1
Встроенны
й разъём
Разъем питания (4 вывод) x2
Задняя
панель
средств
ввода-выв
ода
Клавиатура PS/2 x1
Мышь PS/2 x1
Порт VGA x1
Порт DVI-D x1
Порт LAN x1
USB-порт x4
Гнездо для подключения
наушников x3
Размер
панели
225 мм (Ш) X 305 мм (В) ATX
Поддержка
OS
Windows XP / Vista 32 / Vista 64
Biostar сохраняет за собой право добавлять или
удалять средства обеспечения для OS с или без
предварительного уведомления.
