Motherboard Manual
2
1.3 MOTHERBOARD FEATURES
SPEC
CPU
Socket AM2+ / AM3
AMD Athlon 64 / Athlon 64 FX
/
Athlon 64 x2
/ Sempron / Phenom / Phenom II pro cessors
AMD 64 Architecture enables 32 and 64 bit
comput ing
Supports Hyper Transport 3.0 and PowerNow
FSB
Support HyperTransport 3.0
Supports up to 5.2 GT/s Bandwidth
Chipset
AMD 790GX
AMD SB750
Super I/O
ITE 8718
Provides the most commonly used legacy
Super I/O functionality.
Low Pin Count Interface
Environment Control in it iatives,
H/W Monitor
Fan Sp eed Contro ller
ITE's "S mart Guard ian" function
Main
Memory
DDR2 DIMM Slots x 4
Max Memory Capacity 16GB
Each DIMM supports 256MB/512MB/
1GB/2GB/4GB DDR2
Dual Channel Mode DDR2 memory module
Supports DDR2 533 / 667 / 800
Supports DDR2 1066 (by AM2+ / AM3 CPU)
Registered DIMM and ECC DIMM is not supported
Graphics Radeon HD 3300
Onboard side port memory 128MB DDR2
Max Shared V id eo Memory is 512 MB
DX10/UVD/HDCP support
(Hybrid) CrossFireX support (by ATI driver)
IDE AMD SB750
Ultra DMA 33 / 66 / 100 / 133 Bus Master Mode
supports PIO Mode 0~4,
SATA II AMD SB750
Data transfer rates up to 3 Gb/s.
SATA Version 2.0 specificat ion co mp liant.
RAID 0,1,5,1+0 support
LAN Realtek RTL 8111DL
10 / 100 Mb/s / 1Gb/s auto negotiation
Half / Full duplex capability
Sound ALC888
7.1channels audio out
Supports HD Audio
