Biostar TA790GXE 128M Версия 5.x [7/69] Otherboard

TA790GXE 128M

1.5 MOTHERBOARD LAYOUT

KBMS 1

HDMI1

VGA

DVI

USB1

RJ45USB1

AUDIO2

JUSBV1

JUSBV 2

JCMOS1

AUXPWR1

SYS_FAN1

PEX1_1

PEX16_1

PEX1_2

PCI2

PCI1

PEX16_2

BAT1

LAN

Co de c

F_AUDIO1

SPDIF1

CD_IN1

FDD1

F_USB3 F_USB1F_USB2

PANE L1

SW_PWR

SW_RST

SYS_FAN2

BI O S

Super I/O

SATA1-2

SATA3-4

SATA5-6

IDE1

LED_D1

LED_D2

PH1

PH2

PH3

PH4

ATXPWR2

CPU_FAN1

DIMMA1

DIMMB1

DIMMA2

DIMMB2

Socket AM2+

AMD

790GX

AMD

SB750

ATXPWR1

Note: represents the 1■

pin.
