Biostar TA790GXE 128M Версия 5.x [61/69] Ta790gxe 128m
![Biostar TA790GXE 128M Версия 5.x [61/69] Ta790gxe 128m](/views2/1711577/page61/bg3d.png)
TA790GXE 128M
59
ESPECIFICAÇÕES
Conector da unidade de disquetes x1 Cada conector suporta 2 unidades de disquetes
Conector da para impressora x1 Cada conector suporta 1 Porta para impressora
Conector IDE x1 Cada conector suporta 2 dispositivos IDE
Conector SATA x6 Cada conector suporta 1 dispositivo SATA
Conector do painel frontal x1 Para suporte de várias funções no painel frontal
Conector de áudio frontal x1 Suporta a função de áud io no painel frontal
Conector para entrada d e CDs x1 Suporta a entrada de áudio a p art ir de CDs
Conector de saída S/PD IF x1 Suporta a saída de áud io digital
Conector da ventoinha da CPU x1
Alimentação da vento inha da CPU (com a função Smart
Fan )
Conector da ventoinha do sistema x2 Alimentação da ventoinha do sistema
Conector para limpeza do CMOS x1
Conector USB x3 Cada conector suporta 2 portas USB no painel frontal
Conector de alimentação x1
(24 pinos)
Conectores
na placa
Conector de alimentação x2
(4 p inos)
Entradas/S
aídas no
painel
traseiro
Tec l ad o PS /2 x 1
Rato PS/2 x1
Porta HDMI x1
Porta VGA x1
Porta DVI-D x1
Porta LAN x1
Porta USB x4
Tomada de áudio x6
Tamanho
da placa
225 mm (L) X 305 mm (A) ATX
Sistemas
operativos
suportados
Windows XP / Vista 32 / Vista 64
A Biostar reserva-se o direito de adicionar ou remover
suporte para qualquer sistema operativo com ou sem
av iso prévio.
