TA790GXE 128M
3
SPEC
PCI Slot x2 Supports PCI expansion cards
PCI Express Gen2 x16 Slot x2 Supports PCI-E Gen2 x16 expansion cards
Slots
PCI Express Gen2 x1 Slot x2 Supports PCI-E Gen2 x1 expansion cards
Floppy Connector x1 Each connector supports 2 Floppy drives
IDE Connector x1 Each connector supports 2 IDE device
SATA Connector x6 Each connector supports 1 SATA devices
Front Panel Connector x1 Supports front panel facilities
Front Audio Connector x1 Supports front panel audio function
CD-in Connector x1 Supports CD audio-in function
S/PDIF out Connector x1 Supports digital audio out function
CPU Fan Header x1 CPU Fan power supply (with Smart Fan function)
System Fan Header x2 System Fan Power supply
CMOS clear Header x1 Restore CMOS data to factory default
USB Connector x3 Each connector supports 2 front panel USB ports
Power Connector (24pin) x1 Connects to Power supply
On Board
Connectors
Power Connector (4pin) x2 Connects to Power supply
Back Panel
I/O
PS/2 Keyboard x1
PS/2 Mouse x1
HDMI port x1
VGA port x1
DVI-D port x1
LAN port x1
USB Port x4
Audio Jack x6
Connects to PS/2 Keyboard
Connects to PS/2 Mouse
Connect to HDTV
Connect to D-SUB monitor
Connect to DVI monitor
Connect to RJ-45 ethernet cable
Connect to USB devices
Provide Audio-In/Out and microphone connection
Board Size 225 mm (W) x 305 mm (L) ATX
OS Support
Windows XP / Vista 32 / Vista 64
Biostar reserves the right to add or remove support
for any OS With or without notice.
