NF520-A2 TE/NF520-A2 SE/NF520-A2
29
NF520-A2 TE/NF520-A2 SE NF520-A2
Audio-Codec
Realtek ALC662 (NF520-A2 TE) (Ver 6.x)
Realtek ALC861VD (NF520-A2 SE) (Ver 6. x)
Realtek ALC888 (Ver 5. x)
5.1-Kanal-Audioausgabe (Ver 6. x)
7.1-Kanal-Audioausgabe (Ver 5. x)
Unterstützt High-Definition Audio
Realtek ALC861VD (Ver 6.x)
Realtek ALC888 (Ver 5. x)
5.1-Kanal-Audioausgabe (Ver 6. x)
7.1-Kanal-Audioausgabe (Ver 5. x)
Unterstützt High-Definition Audio
PCI-Steckplatz x3 PCI-Steckplatz x3
PCI Express x16 Steckplatz x1 PCI Express x16 Steckplatz x1 Steckplätze
PCI Express x 1-Steckplatz x2 PCI Express x 1-Steckplatz x2
Diskett enlaufwerkansc hluss x1 Diskett enlaufwerkansc hluss x1
Druc keransc hluss Ansc hluss x1 Druc keransc hluss Ansc hluss x1
IDE-Ansc hluss x1 IDE-Ansc hluss x1
SATA-Anschluss x4 SATA-Anschluss x2
Fronttafelanschluss x1 Fronttafelanschluss x1
Front-Audioansc hluss x1 Front-Audioansc hluss x1
CD-IN-A nsc hluss x1 CD-IN-A nsc hluss x1
S/PDIF- Ausgangsanschluss x1 S/PDIF- Ausgangsanschluss x1
CPU-Lüfter-Sockel x1 CPU-Lüfter-Sockel x1
System-Lüfter-Sockel x1 System-Lüfter-Sockel x1
"CMOS löschen"-Sockel x1 "CMOS löschen"-Soc kel x1
"Gehäuse offen"-Sockel(optional) x1 "Gehäuse offen"-Sockel(optional) x1
US B-Ansc hluss x3 US B-Ansc hluss x2
Stromanschluss (24-polig) x1 Stromanschluss (24-polig) x1
Onboard-Ansc
hluss
Stromanschluss (4-polig) x1 Stromanschluss (4-polig) x1
Rückseiten-E/
A
PS/2-Tastatur x1
PS/2-Maus x1
Serieller Ansc hluss x1
LAN-Ansc hluss x1
US B-Ansc hluss x4
Audioanschluss (Ver 6.x) x3
Audioanschluss (Ver 5.x) x6
PS/2-Tastatur x1
PS/2-Maus x1
Serieller Ansc hluss x1
LAN-Ansc hluss x1
US B-Ansc hluss x4
Audioanschluss (Ver 6.x) x3
Audioanschluss (Ver 5.x) x6
Platinengröße. 200 mm (B) X 293 mm (L) 200 mm (B) X 293 mm (L)
Sonderfunktio
nen
Unterstützt RAID 0 / 1 / 0+1 Unterstützt RAID 0 / 1
OS-Unterstütz
ung
Windows 2K / XP / VISTA
Biostar behält sich das Recht vor, ohne
Ankündigung die Unterstütz ung für ein
Betriebssystem hinzuzufügen oder zu
entfernen.
Windows 2K / XP / VISTA
Biostar behält sich das Recht vor, ohne
Ankündigung die Unterstütz ung für ein
Betriebssystem hinzuzufügen oder zu
entfernen.
