Motherboard Manual
2
1.3 MOTHERBOARD FEATURES
NF520-A2 TE/NF520-A2 SE NF520-A2
CPU
Socket AM2
AMD Athlon 64 / Athlon 64 FX / Althlon 64 X2 /
Sempron processors
AMD 64 Architec ture enables 32 and 64 bit
computing
Supports Hyper Transport and Cool=n=Quiet
Socket AM2
AMD Athlon 64 / Athlon 64 FX / Althlon 64 X2 /
Sempron processors
AMD 64 Architec ture enables 32 and 64 bit
computing
Supports Hyper Transport and Cool=n=Quiet
FSB
Support HyperTransport
Supports up to 1GHz Bandwidth
Support HyperTransport
Supports up to 1GHz Bandwidth
Chipset nForc e 520 nForc e 520LE
Super I/O
ITE 8716F
Provides the most commonly used legacy Super
I/O functionality.
Low Pin Count Interface
Environment Control initiatives,
H/W Monitor
Fan Speed Controller
ITE's "Smart Guardian" function
ITE 8716F
Provides the most commonly used legacy Super
I/O functionality.
Low Pin Count Interface
Environment Control initiatives,
H/W Monitor
Fan Speed Controller
ITE's "Smart Guardian" function
Main
Memory
DDR2 DIMM Slot x 4
Eac h DIMM supports 256/512/1024/2048 MB
DDR2
Max Memory Capicity 8G
Dual Channel Mode DDR2 memory module
Supports DDR2 533/667/800
Registered DIMM and ECC DIMM is not
supported
DDR2 DIMM Slot x 4
Eac h DIMM supports 256/512/1024/2048 MB
DDR2
Max Memory Capicity 8G
Dual Channel Mode DDR2 memory module
Supports DDR2 533/667/800
Registered DIMM and ECC DIMM is not
supported
IDE
Integrated IDE Controller
Ultra DMA 33 / 66 / 100 / 133 Bus Master Mode
supports PIO Mode 0~4,
Integrated IDE Controller
Ultra DMA 33 / 66 / 100 / 133 Bus Master Mode
supports PIO Mode 0~4,
SA TA
Integrated Serial ATA Controller
Data transfer rates up to 3.0 Gb/s.
SATA Version 2.0 specification compliant.
Integrated Serial ATA Controller
Data transfer rates up to 3.0 Gb/s.
SATA Version 2.0 specification compliant.
LAN
Realtek RTL8201CL PHY
10/100 Mb/s auto negotiation
Half / Full duplex capability
Realtek RTL8201CL PHY
10/100 Mb/s auto negotiation
Half / Full duplex capability
