Motherboard Manual
2
1.3 MOTHERBOARD FEATURES
TF520- A2 TF560- A2
CPU
Socket AM2
AMD Athlon 64 / Athlon 64 x2 / Sempron
processors
AMD 64 Architecture enables 32 and 64 bit
comput ing
Supports Hyper Transport and Cool=n=Quiet
Socket AM2
AMD Athlon 64 / Athlon 64 x2 / Sempron
processors
AMD 64 Architecture enables 32 and 64 bit
comput ing
Supports Hyper Transport and Cool=n=Quiet
FSB
Support up to 1 GHz Bandwidth
Support HyperTransport
Support up to 1 GHz Bandwidth
Support HyperTransport
Chipset nVIDIA nForce 520 nVIDIA nForce 560
Super I/O
ITE 8716F
Provides the most commonly used legacy Super
I/O functionality.
Low Pin Count Interface
Environment Control init iatives,
H/W Monitor
Fan Sp eed Controller
ITE's "S mart Guardian" function
ITE 8716F
Provides the most commonly used legacy Super
I/O functionality.
Low Pin Count Interface
Environment Control init iatives,
H/W Monitor
Fan Sp eed Controller
ITE's "S mart Guardian" function
Main
Memory
DIMM Slots x 4
Each DIMM supports 256/512MB & 1GB/2GB
DDR2
Max Memory Capicity 8GB
Dual Channel Mode DDR2 memory module
Supports DDR2 533 / 667 / 800
Registered DIMM and ECC D IMM is not
supported
DIMM Slots x 4
Each DIMM supports 256/512MB & 1GB/2GB
DDR2
Max Memory Capicity 8GB
Dual Channel Mode DDR2 memory module
Supports DDR2 533 / 667 / 800
Registered DIMM and ECC D IMM is not
supported
IDE
Integr ated IDE Contro ller
Ultra DMA 33 / 66 / 100 / 133 Bus Master Mode
supports PIO Mode 0~4.
Integr ated IDE Contro ller
Ultra DMA 33 / 66 / 100 / 133 Bus Master Mode
supports PIO Mode 0~4.
SATA II
Integrated Serial ATA Controller
Data transfer rates up to 3 Gb/s.
SATA Version 2.0 spec if icat ion co mp liant.
Integrated Serial ATA Controller
Data transfer rates up to 3 Gb/s.
SATA Version 2.0 spec if icat ion co mp liant.
LAN
Realtek RTL 8110SC / 8100C (optional)
10 / 100 Mb/s / 1Gb/s auto negotiation (Gigabit
bandwidth is for RTL 8110SC only)
Half / Full duplex capability
Realtek RTL 8110SC / 8100C (optional)
10 / 100 Mb/s / 1Gb/s auto negotiation (Gigabit
bandwidth is for RTL 8110SC only)
Half / Full duplex capability
