TF520-A2/TF560-A2
49
TF520- A2 TF560- A2
Códecs de
sonido
ALC888 (Ver 5.x) / ALC662 (Ver 6.x)
Salida de sonido de 7.1 canales (ALC888)
Salida de sonido de 5.1 canales (ALC662)
Soporte de sonido de Alta Definición
ALC888 (Ver 5.x) / ALC662 (Ver 6.x)
Salida de sonido de 7.1 canales (ALC888)
Salida de sonido de 5.1 canales (ALC662)
Soporte de sonido de Alta Definición
Ranura PCI X3 Ranura PCI X3
Ranura PCI Express x16 X1 Ranura PCI Express x16 X1
Ranuras
Ranura PCI express x 1 X2 Ranura PCI express x 1 X2
Conector disco flexible X1 Conector disco flexible X1
Conector Puerto de impresora X1 Conector Puerto de impresora X1
Conector IDE X1 Conector IDE X1
Conector SATA X4 Conector SATA X4
Conector de panel frontal X1 Conector de panel frontal X1
Conector de sonido frontal X1 Conector de sonido frontal X1
Conector de entrada de CD X1 Conector de entrada de CD X1
Conector de salida S/PDIF X1 Conector de salida S/PDIF X1
Cabecera de ventilador de CPU X1 Cabecera de ventilador de CPU X1
Cabecera de ventilador de sistema X2 Cabecera de ventilador de sistema X2
Cabecera de borrado de CMOS X1 Cabecera de borrado de CMOS X1
Conector USB X2 Conector USB X2
Conector de alimentación X1
(24 patillas)
Conector de alimentación X1
(24 patillas)
Conector de alimentación X1
(8 patillas)
Conector de alimentación X1
(8 patillas)
Conectores
en placa
Conector de alimentación X1
(4 patillas)
Conector de alimentación X1
(4 patillas)
Panel
trasero de
E/S
Tec lado PS /2 X 1
Ratón PS/2 X1
Puerto serie X1
Puerto de red local X1
Puerto USB X6
Conector de sonido (Ver 5.x) X6
Conector de sonido (Ver 6.x) X3
Tec lado PS /2 X 1
Ratón PS/2 X1
Puerto serie X1
Puerto de red local X1
Puerto USB X6
Conector de sonido (Ver 5.x) X6
Conector de sonido (Ver 6.x) X3
Ta maño d e
la placa
244 mm. (A) X 305 Mm. (H) 244 mm. (A) X 305 Mm. (H)
Funciones
especiales
NVIDIA nTunes
Admite RAID 0 / 1 / 0+1
NVIDIA nTunes
Admite RAID 0 / 1 / 0+1 / 5
Soporte de
sistema
operativo
Windows 2K / XP / VISTA
Biostar se reserva el derecho de añadir o retirar
el soporte de cualquier SO con o sin aviso previo.
Windows 2K / XP / VISTA
Biostar se reserva el derecho de añadir o retirar
el soporte de cualquier SO con o sin aviso previo.
