Si34-601A Protection Control
Function 119
4.2 Low Pressure Protection Control
This low pressure protection control is used to protect compressors against the transient
decrease of low pressure.
[In cooling operation]
★
In the case of multi-outdoor-unit system, the entire system performs this control in the
following sequence.
[In heating operation]
★
In the case of multi-outdoor-unit system, each outdoor unit performs this control
individually in the following sequence.
Low pressure not limited
Pe<0.34MPa
Low pressure standby
Low pressure limited
All STD compressors
stop.
Master unit:52 Hz + OFF + OFF
Slave unit:Stop
Pe<0.25MPa
Pe<0.15MPa Pe>0.30MPa
Pe>0.39MPa
Pe<0.07MPa
Pe: LP pressure sensor detection
value for master unit
When occurring 4 times within 30 min.,
the malfunction code “ E4 ” is output.
Hot gas SVP = OFF
Hot gas SVP = ON
Pe<0.17 MPa
Pe<0.13 MPa
Pe >0.23 MPa
INV upper limit Hz = MAX
Pe<0.07 MPa
&
Low pressure not limited
Low pressure standby
Low pressure limited
INV upper limit frequency: 1-step
up from current compressor
frequency
52 Hz + OFF + OFF
Pe: LP pressure sensor detection
value for each outdoor unit
Pe
After 15 sec.
>0.20 MPa
Pe<0.17 MPa
When occurring 4 times within 30 min.,
the malfunction code “E4” is output.
INV upper limit frequency:
3-step down from current
compressor frequency
Pe<0.12MPa Pe>0.17MPa
Hot gas SVP = OFF
Hot gas SVP = ON
After 10 sec.
After 10 sec.
