Indoor Units Line Up
2625
Ceiling Mounted
Cassette
(Double-flow)
Type
Ceiling Mounted
Cassette
(Multi-flow)
Super Cassette
600X600
Multi Flow
Ceiling Mounted
Cassette
Ceiling Mounted
Cassette Corner
Ceiling Mounted
Built-in
Wall Mounted
Floor Standing
Concealed Floor
Standing
FXCQ-MVE
FXFQ-MVE
FXHQ-MAVE
Capacity range
Capacity index
FXZQ-M8V1B
FXLQ-MAVE
FXNQ-MAVE
FXMQ-MAVE
Model name
20 25 31.25 40 50 62.5 80 100 125 145 200
2.2 kW 2.8 kW 3.6 kW 4.5 kW 5.6 kW 7.1 kW 9 kW 11.2 kW 14 kW 16.2 kW 22.4 kW
FXDQ-NAVE
(900/1,100 mm
width type)
FXSQ-MVE
FXDYQ-MV1
Ceiling Concealed
(Duct)
Ceiling
Suspended
Ceiling Mounted
Duct
FXAQ-MAVE
Ceiling
Suspended
Cassette
Type
—
4.5 kW2.2 kW 3.6 kW2.8 kW
FXUQ-MAV1
Model name
20 4031.2525
BEVQ125MAVE
14 kW
BEVQ100MAVEBEVQ71MAVE
5.6 kW 11.2 kW8 kW
50 12510071
• Indoor units in the 63 class are not available for the above models.
• BEV units are necessary for Connection unit series indoor units. Refer to the Engineering Data for details.
Notes:
• R410A VRV system indoor units are not compatible with the R22 VRV system.Note:
Connection unit series indoor units
Capacity Range
Connection Unit
Capacity Index
Slim Ceiling
Mounted Duct
FXKQ-MAVE
FXDQ-PVE
(700 mm
width type)
250
28 kW
180
20 kW
Ceiling mounted cassette (double-flow) type
Thin, lightweight, and easy to install in
shallow ceiling spaces
FXCQ20M/FXCQ25M/FXCQ32M
FXCQ40M/FXCQ50M/FXCQ63M
FXCQ80M/FXCQ125M
600 mm
Class 20
32/27
25/32
34/28
63
37/32
40/50
34/29
80
39/34
125
44/38
34/29 36/30 39/3437/32 41/36 46/40
(dB(A))
350mm
The low profile unit (only 350 mm high) can
be installed in a ceiling space as shallow
as 355 mm. All models feature a compact
design with a depth of only 600 mm.
(When a high-efficiency filter is attached, the
unit's height is 400mm.)
Low operating sound
Designed with higher air flow suitable for
high ceiling application up to 3 metres.
Providing 2 different settings of standard
and ceiling soiling prevention, the auto
swing mechanism achieves even
distribution of airflow and room
temperature.
Two types of optional high-efficiency filter are
available (65% and 95% NBS).
A long-life filter (maintenance free up to one
year) is equipped as standard accessory.
Drain-up pump is equipped as standard
accessory with 600 mm lift.
Major maintenance work can be performed by
removing the panel. A flat-type suction grille
and a detachable blade make cleaning easy.
220V
240V
Operating
