Motherboard Manual
2
1.3 MOTHERBOARD FEATURES
Ver 5.x Ver 6.x
CPU
Socket 754
AMD Sempron / Athlon 64 processors
Supports Hyper Transport and Cool=n=Quiet
Socket 754
AMD Sempron / Athlon 64 processors
Supports Hyper Transport and Cool=n=Quiet
FSB Supports up to 800MHz Bandwidth Supports up to 800MHz Bandwidth
Chipset MCP61S (GeForce 6100-405) MCP61S (GeForce 6100-405)
Super I/O
ITE 8712F
Provides the most common ly used legacy Super
I/O functionality.
Low Pin Count Interface
ITE 8712F
Provides the most common ly used legacy Super
I/O functionality.
Low Pin Count Interface
Main
Memory
DIMM Slots x 2
Each DIMM supports 256/512MB & 1GB DDR
Max Memory Capicity 2GB
Sing le C hann e l Mode DDR memo r y module
Supports DDR 400 / 333
Registered DIMM and ECC DIMM is not
supported
DIMM Slots x 2
Each DIMM supports 256/512MB & 1GB DDR
Max Memory Capicity 2GB
Sing le C hann e l Mode DDR memo r y module
Supports DDR 400 / 333
Registered DIMM and ECC DIMM is not
supported
Graphics
Int egrated in MC P61S Ch ips et
Max Shared V id eo Me mory is 256 MB
Int egrated in MC P61S Ch ips et
Max Shared V id eo Me mory is 256 MB
IDE
Integr at ed IDE Contro lle r
Ultra DMA 33 / 66 / 100 / 133 Bus Master Mode
supports PIO Mode 0~4
Integr at ed IDE Contro lle r
Ultra DMA 33 / 66 / 100 / 133 Bus Master Mode
supports PIO Mode 0~4
SATA II
Integrated Serial ATA Controller
Data transfer rates up to 3.0 Gb/s.
SATA Version 2.0 s pecif ic at ion co mp liant.
Integrated Serial ATA Controller
Data transfer rates up to 3.0 Gb/s.
SATA Version 2.0 s pecif ic at ion co mp liant.
LAN
Realtek 8201CL PHY
10 / 100 Mb/s Auto-Negotiation
Realtek 8201CL PHY
10 / 100 Mb/s Auto-Negotiation
Sound
ALC888
7.1 channels audio out
High-Definition Audio support
ALC861VD
5.1 channels audio out
High-Definition Audio support
