NF61S Micro 754
5
1.6 MOTHERBOARD LAYOUT (VER 6.X)
JKBMS1
JCOM1
JVGA1
JUSB1
JUSBLAN1
JAUDIO1
LAN
Codec
JCDIN1
JPRNT1
FDD1
Super I/O
BIOS
JPANEL1
JSFAN1
JUSB3
JUSB2
JCMOS1
JUSBV2
SATA2 SATA1
IDE1
DIMM1
DIMM2
JDDR _OV<3V
JATXPWR2
JUSBV1
JATXPWR1
JNFAN1(Optional)
PEX1_1
PCI1
PCI2
BAT1
JAUDIOF1
JCI1(Optional)
JCFAN1
PEX16_1
MCP61S
Socket 754
CPU1
Note: represents the 1■
st
pin.
