NF61S Micro 754
3
Ver 5.x Ver 6.x
PCI slot x2 PCI slot x2
PCI Express x 16 slot (x8 Speed) x1 PCI Express x 16 slot (x8 Speed) x1
Slots
PCI Express x 1 slot x1 PCI Express x 1 slot x1
Floppy connector x1 Floppy connector x1
IDE Conn ect or x1 IDE Conn ector x1
SATA2 Connector x2 SATA2 Connector x2
Front Panel Connector x1 Front Panel Connector x1
Front Audio Connector x1 Front Audio Connector x1
CD-in Connector x1 CD-in Connector x1
CPU Fan header x1 CPU Fan header x1
System Fan header x1 System Fan header x1
CMOS clear header x1 CMOS clear header x1
USB connector x2 USB connector x2
Printer Port Connector x1 Printer Port Connector x1
Chassis open header(Optional) x1 Chassis open header(Optional) x1
Power Connector (24pin) x1 Power Connector (24pin) x1
On Board
Connector
Power Connector (4pin) x1 Power Connector (4pin) x1
Back Panel
I/O
PS/2 Keyboard x1
PS/2 Mouse x1
Serial Port x1
VGA port x1
LAN port x1
USB Port x4
Audio Jack x6
PS/2 Keyboard x1
PS/2 Mouse x1
Serial Port x1
VGA port x1
LAN port x1
USB Port x4
Audio Jack x3
Board Size 207 x 244 (mm) 207 x 244 (mm)
Special
Features
NVIDIA nTunes
RAID 0 / 1 support
NVIDIA nTunes
RAID 0 / 1 support
OS Support
Windows 2000 / XP / VISTA
Biostar Reserves the right to add or remove
support for any OS With or without notice.
Windows 2000 / XP / VISTA
Biostar Reserves the right to add or remove
support for any OS With or without notice.
