24
Create, click “Save” button to save your configure.
4.3 Site Survey
The Site Survey tab, displays a list of infrastructure and ad-hoc networks available for
connection
.
Figure 4-18
Filter button – It can filter Network SSID, Network BSSID and Select Channel. Network SSID
and Network BSSID can filter any one or only one. Select Channel can filter all channel, only
one channel or channel of in a certain range.
