Daikin RXYMQ5PVE [2/20] Outdoor unit can be installed on a balcony
![Daikin RXYMQ5PVE [2/20] Outdoor unit can be installed on a balcony](/views2/1712404/page2/bg2.png)
SS
The
5S+1E
concepts of
Extending the core “5S” concept—Space saving, Sufficient capacity, Slim design, Sound-
reduced operation and Single phase power supply—Daikin’s VRVIII-S offers added value
with the “1E” concept—Easy installation. With all these features and more, we proudly
present the ideal air conditioning system designed for small-sized buildings.
The ideal air conditioning system for
small offices and shops
S
pace saving
S
ufficient capacity
S
lim design
S
ound-reduced operation
S
ingle phase power supply
E
asy installation
E
1E
concept
5S
concept
21
765 mm
The VRVIII-S is highly space saving, featuring slim and compact
outdoor units. It is suitable for small offices and shops with capacities
of 4, 5 and 6 HP.
Slim, compact and sufficient capacity
Approx.
40%
reduction
Approx.
50%
reduction
635 mm
900 mm
320 mm
Volume
VRVIII
(5 HP)
Footprint
(4, 5, 6 HP)
VRVIII
(5 HP)
(4, 5, 6 HP)
The compact, trunk-shaped outdoor unit can easily
be installed on a balcony, realising complete system
installation within each floor. This enables more
useful utilisation of the space on the building rooftop.
Outdoor unit can be installed
on a balcony
Introduction.......... page 1
Main features........page 3
Control systems... page 9
Indoor unit lineup..... page 15
Specifications........... page 25
Indoor units............... page 25
Outdoor units............ page 32
Option list............ page 33
Indoor units......... page 33
Outdoor units.......page 35
Control systems...page 35
Contents
