Wide range of choices
To suit the variety of rooms found in small offices
and shops, the VRVIII-S system offers wide range of
indoor and outdoor units.
VRVIII-S indoor and outdoor units are almost as easy
to install as residential air conditioning systems,
making them ideal for small offices and shops.
MAIN FEATURES
Outdoor unit can be selected from three
models to provide the power that suits
your needs. The trunk-shaped outdoor unit
can be neatly installed outside the office.
A wide range of indoor units includes
71 models in 14 types. The indoor
units can be selected to match every
room and preference.
14 types 71 models*
3 models
Indoor units
Outdoor units
43
Indoor unit lineup
Connection unit series indoor units (50 Hz only)
14 types 71 models*
Ceiling Mounted
Cassette
(Double Flow)
Ceiling Mounted
Cassette
(Round Flow)
FXCQ-MVE
FXFQ-PVE
Slim Ceiling
Mounted Duct
Ceiling Mounted
Duct
Ceiling Suspended
Wall Mounted
Floor Standing
Concealed
Floor Standing
Ceiling Mounted
Cassette Corner
FXDQ-NBVE
(with drain pump)
FXDQ-NBVET
(without drain pump)
FXMQ-PVE
FXHQ-MAVE
FXAQ-PVE
FXLQ-MAVE
FXNQ-MAVE
FXKQ-MAVE
FXDQ-PBVET
(without drain pump)
FXDQ-PBVE
(with drain pump)
(700 mm width type)
(900/1,100 mm width type)
R-410A VRV system indoor units are not compatible with the R-22 VRV system.Note:
BEV units are necessary for Connection unit series indoor units. Refer to the Engineering Data Book for details.Note:
*
13 types and 68 models for 60 Hz specifications.
New
Ceiling Mounted
Cassette
(Compact Multi Flow)
FXZQ-MVE
Ceiling Suspended
Cassette
—
1.6 HP0.8 HP 1.25 HP1 HP
FXUQ-MAV1
20 4031.2525
BEVQ125MAVE
5 HP
BEVQ100MAVEBEVQ71MAVE
2 HP 4 HP3 HP
50 12510071
Capacity Range
Connection Unit
Capacity Index
Type Model Name
New
New New New
New New
Model Name
Capacity Range
Capacity Index
RX(Y)MQ4PVE RX(Y)MQ5PVE RX(Y)MQ6PVE
4 HP (11.2 kW) 5 HP (14.0 kW) 6 HP (15.5 kW)
100 125 140
Outdoor unit lineup
Capacity Range
Capacity Index
20 40 62.5 80 100 1255031.2525
0.8 HP 1.6 HP 2.5 HP 3.2 HP 4 HP 5 HP2 HP1.25 HP1 HP
20 40 63 80 100 125
140
6 HP
140503225
Type Model Name
