Ariston CP65SG1 [15/76] Installation

! Before operating your new appliance please read

this instruction booklet carefully. It contains

important information concerning the safe installation

and operation of the appliance.

! Please keep these operating instructions for future

reference. Pass them on to possible new owners of

the appliance.

! The appliance must be installed by a qualified

professional in accordance with the instructions

provided.

! Any necessary adjustment or maintenance must be

performed after the cooker has been disconnected

from the electricity supply.

Room ventilation

The appliance may only be installed in permanently

ventilated rooms, in accordance with current national

legislation and any subsequent amendments in

force. The room in which the appliance is installed

must be ventilated adequately in order to provide as

much air as is needed by the normal gas

combustion process (the flow of air must not be

lower than 2 m

/h per kW of installed power).

The air inlets, protected by grilles, should have a

duct with an inner cross section of at least 100 cm

and should be positioned so that they are not liable

to even partial obstruction (

see figure A

These inlets should be enlarged by 100% - with a

minimum of 200 cm

- whenever the surface of the

hob is not equipped with a flame failure safety

device. When the flow of air is provided in an

indirect manner from adjacent rooms (

see figure B

provided that these are not communal parts of a

building, areas with increased fire hazards or

bedrooms, the inlets should be fitted with a

ventilation duct leading outside as described above.

! After prolonged use of the appliance, it is

advisable to open a window or increase the speed of

any fans used.

Disposing of combustion fumes

The efficient disposal of combustion fumes should

be guaranteed using a hood which is connected to a

safe and efficient natural suction chimney, or using

an electric fan which begins to operate automatically

every time the appliance is switched on (

see figure

! The liquefied petroleum gases are heavier than air

and collect by the floor, therefore all rooms

containing LPG cylinders must have openings

leading outside so that any leaked gas can escape

easily.

LPG cylinders, therefore, whether partially or

completely full, must not be installed or stored in

rooms or storage areas which are below ground level

(cellars, etc.). Only the cylinder being used should

be stored in the room; this should also be kept well

away from sources of heat (ovens, chimneys,

stoves) which may cause the temperature of the

cylinder to rise above 50°C.

Positioning and levelling

! The appliance may be installed alongside any

cupboards whose height does not exceed that of the

hob surface.

! Make sure that the wall which is in contact with the

back of the appliance is made from a non-

flammable, heat-resistant material (T 90°C).

To install the appliance correctly:

• Place it in the kitchen, the dining room or the

studio flat (not in the bathroom).

• If the top of the hob is higher than the cupboards,

the appliance must be installed at least 600 mm

away from them.

• If the cooker is installed underneath a wall

cabinet, there must be a minimum distance of 420

mm between this cabinet and the top of the hob.

Installation

Adjacent

room

Room

requiring

ventilation

Ventilation opening for

comburent air

Increase in the gap

between the door and

the flooring

Fumes channelled

straight outside

Fumes channelled through a

chimney or a branched flue

system (reserved for cooking

appliances)
