Planet WAP-6000 [5/33] Specification

- -

1.3 Specification

Model WAP-6000

Standard IEEE 802.11b, 802.11g

Signal Type DSSS (Direct Sequence Spread Spectrum)

Modulation OFDM with BPSK, QPSK, 16QAM, 64QAM, DBPSK, DQPSK, CCK

Port 10/100Mbps RJ-45 port * 1

Antenna Connector

Reverse N-type male * 1

Output Power 18dBm@11Mbps / 14dBm@54Mbps (typical)

5 levels adjustable (Full, Half, Quarter, Eighth, Minimum)

Sensitivity

-74dBm@54Mbps OFDM, 10% PER

-88dBm@11Mbps CCK, 8% PER

Operating Mode AP, AP with WDS (Bridge), Wireless Client, Repeater

Security

WEP setting

- Authentication type: Open System / Shared Key

- Shared keys input type: HEX / ASCII

- Shared keys length: (64-bit, 128-bit, 152-bit)

- Default WEP Key to use (1-4)

WPA-PSK setting

- PassPhrase

- WPA Cipher Type (Auto, TKIP, AES)

- Group Key Update Interval: 300

WPA setting

- Radius Server IP Address

- Radius Port: 1812

- WPA Cipher Type (Auto, TKIP, AES)

- Shared Key

Group Key Update Interval: 300

Super G mode Up to 108Mbps

802.11g Up to 54Mbps (6/9/12/18/24/36/48/54)

Data Rate

802.11b Up to 11Mbps (1/2/5.5/11)

Dimensions (L x W x H)

232 x 185 x 62mm

Weight 1130g

Environmental

Specification

Operating temperature: -20 – 70 degree C

Storage temperature: -30 – 80 degree C

Relative humanity: 0% – 90% (non-condensing)
