4
GB
Connecting the supply cable to the mains
Install a standardised plug corresponding to the load
indicated on the data plate (
see side
).
The appliance must be directly connected to the
mains using an omnipolar circuit-breaker with a
minimum contact opening of 3 mm installed between
the appliance and the mains, suitable for the load
indicated and complying with current electrical
regulations (the earthing wire must not be interrupted
by the circuit-breaker). The supply cable must not
come into contact with surfaces with temperatures
higher than 50°C.
! The installer must ensure that the correct electrical
connection has been made and that it is compliant
with safety regulations.
Before connecting to the power supply, make sure
that:
• The appliance is earthed and the plug is compliant
with the law.
• The socket can withstand the maximum power of
the appliance, which is indicated on the data plate
(
see below
).
• The voltage must be in the range between the
values indicated on the data plate (
see below
).
• The socket is compatible with the plug of the
appliance. If the socket is incompatible with the
plug, ask an authorised technician to replace it. Do
not use extension cords or multiple sockets.
! Once the appliance has been installed, the power
supply cable and the electrical socket must be easily
accessible.
! The cable must not be bent or compressed.
! The cable must be checked regularly and replaced
by authorised technicians only (
see Assistance
).
! The manufacturer declines any liability should
these safety measures not be observed.
DATA PLATE
Dimensions
width 43.5 cm
height 32 cm
depth 41,5 cm
Volume lt. 58
Ele ct ric al
connections
voltage: 230V/400V~ 3N 50/60Hz or
50Hz (see dat a pl ate)
maximum po wer ab sorbed 10800W
or 10700W
(
see data
p
late
)
ENERGY LABEL
Directive 2002/40/EC on the lab el of
electric ovens.
Standard EN 50304
Energy consumptio n for Natural
co nvection – heati ng mode: /
Convection mode.
Declared energy consumption for
Fo rced convection Cl ass – heating
mode: / Baking.
Th is a pplian ce conforms to the
f ollowi ng European Economic
Community directives:
2006/95/EEC o f 12/ 12/0 6 (Low
Voltage) and subsequent
amendments;
- 2004/108/EEC of 15/12/04
(Electromagnetic Compatibility) and
su bsequent amendments;
- 93/68/EEC of 22/07/93 and
su bsequent amendments.
- 2002/96/EC and subsequent
amendments.
Assistance
Communicating:
• appliance model (Mod.)
• serial number (S/N)
This information is found on the data plate located on the appliance and/or on the packaging.
