6L(1%( :LULQJ'LDJUDPVIRU5HIHUHQFH
$SSHQGL[
);+40$0$0$9(
3D039801D
INDOOR UNIT
A1P Printed circuit board
C1R Capacitor (M1F)
F1U Fuse (훾 5A, 250V)
HAP Light emitting diode
(service monitor-green)
KAR Magnetic relay (M1S)
KPR Magnetic relay (M1P)
M1F Motor (Indoor fan)
M1S Motor (Swing flap)
Q1M Thermo switch (M1F embedded)
R1T Thermistor (Air)
R2T Thermistor (Coil liquid)
R3T Thermistor (Coil gas)
S1Q Limit witch (Swing flap)
T1R Transformer (220-240V/22V)
X1M Terminal block (Power)
X2M Terminal block (Control)
Y1E Electronic expansion valve
Phase control circuit
OPTIONAL PARTS
M1P Motor (Drain pump)
WIRED REMOTE CONTROL
R1T Thermistor (Air)
SS1 Selector switch (Main/Sub)
RECEIVER/DISPLAY UNIT (ATTACHED
TO INFRARED REMOTE CONTROL
A2P Printed circuit board
A3P Printed circuit board
BS1 Push button (on/off)
H1P Light emmitting diode (on-red)
H2P Light emmitting diode
(timer-green)
Electric part box
1. : Terminal block : Connector
: Short circuit connector
2. : Field wiring
3. In case using central remote control, connect it to the unit in
accordance with the attached instruction manual.
4. X23A is connected when the infrared remote control kit is
being used.
5. When connecting the input wires from outside, forced off or
on/off control operation can be selected by remote control.
In details, refer to the installation manual attached the unit.
6. In case installing the drain pump, remove the short circ
uit
connector of X8A and execute the additional wiring for float
switch and drain pump.
7. Symbols shows as follows: PNK:PINK WHT:WHITE YLW:YELLOW
ORG:ORANGE BLU:BLUE BLK:BLACK RED:RED
8 Use copper conductors only.
Note-5
Input from outside
Note-3
Transmission wiring
central remote control
Wired remote control
(optional accessory)
NOTES
Power supply
Note-6
H3P Light emmitting diode
(filter sign-red)
H4P Light emmitting diode
(defrost-orange)
SS1 Selector switch (Main/sub)
SS2 Selector switch
(Wireless address set)
CONNECTOR FOR OPTIONAL PARTS
X8A Connector (Float switch)
X18A Connector (Wiring adapter for
electrical appendices)
X23A Connector
(Infrared remote control)
Note-4
Receiver/display unit
(Infrared remote control)
PC
