14
lnstallation Guide
18
Depending on requirement or preference,
adhere four rubber stands for horizontal
use or install the rubber pads for vertical
use. Corresponding RAVEN logo for
each orientation are included for installation
Bringen Sie je nach Anforderungen oder
Präferenzen vier Gummifüße zur
horizontalen Nutzung auf oder installieren
die Gummipolster zur vertikalen Nutzung.
Ein entsprechendes RAVEN-Logo ist für
die jeweilige Installationsausrichtung
mitgeliefert
Selon les exigences ou les préférences,
mettez quatre pieds en caoutchouc pour
une utilisation horizontale ou installez les
patins en caoutchouc pour une utilisation
verticale. Le logo RAVEN correspondant
pour chaque sens est inclus pour
l'installation
Dependiendo de los requisitos o
preferencias, adhiera cuatro patas de
goma para un uso horizontal o instale el
acolchamiento de goma para un uso
vertical. Se incluye el correspondiente
logo RAVEN para cada orientación
In base ai requisiti o alle preferenze, fare
aderire Quattro supporti di gomma per
l’uso orizzontale, oppure installare i
cuscinetti di gomma per l’uso verticale.
Per l'installazione sono inclusi logo
RAVEN per ogni orientamento
В зависимости от ваших требований или
предпочтений установите четыре резиновых
стойки для использования в горизонтальном
положении или четыре резиновых прокладки
для использования в вертикальном
положении. Для установки в нужном
положении пользуйтесь соответствующим
логотипом RAVEN из комплекта поставки
요구 사항 또는 기본 설정에 따라 수평 용도의
고무 스탠드 4개을 부착하거나 수직 용도의
고무 패드를 설치하십시오. 설치를 돕기 위해
각 방향으로 해당 RAVEN 로고가 표시되어
있습니다
視需求決定使用橫躺或是直立的腳墊,並選
擇使用的RAVEN Logo方向
必要条件または設定に従い、横置き使用
のための4つのゴムスタ ンド、または縦
型使用のためのゴムパッドを貼付します。
各方向 に対応するRAVENロゴもインスト
ールに含まれています
视需求决定使用横躺或是直立的脚垫,并选
择使用的RAVEN Logo方向
17
Place the top cover back onto the chassis
and secure with screws
Setzen Sie die obere Abdeckung wieder
auf das Gehäuse auf, fixieren Sie die
Abdeckung mit zwei Schrauben
Remettez le panneau supérieur sur le
boîtier et fixez-le avec deux vis
Vuelva a poner la cubierta superior en la
carcasa y asegúrela con dos tornillos
Riposizionare il cover superiore e serrarlo
per mezzo delle due viti
Установите на место верхнюю крышку
корпуса и закрепите ее два шурупами
상부 커버를 케이스에 재 설치한 후 2개의
나사로 고정시킵니다
裝回上蓋
ケースに上部カバーを戻し、ネジで固定
します
装回上盖
