7
lnstallation Guide
6
Insert the I/O shield included with your
motherboard then install the motherboard
into the chassis
Setzen Sie das mit Ihrem Motherboard
gelieferte I/O-Blech in die Aussparungen
an der Rückseite des Gehäuses ein,
installieren Sie anschließend das
Insérez la plaque d'E/S inclus avec votre
carte mère, puis installez la carte mère
dans le boîtier
Inserte el protector de E/S incluido en
su placa base, luego instale la placa
base en la carcasa
Installare la mascherina I/O inclusa con
la scheda madre, quindi installare la
mainboard nel case
Установите заглушку для разъёмов
задней панели материнской платы,
прилагаемую к материнской плате, затем
установите материнскую плату в корпус
메인보드와 같이 동봉된 I/O Shield 를
삽입한 후, 메인보드를 케이스에설치합
니다
將I/O彈片裝上機殼,裝上主機板
お持ちのマザーボードに付属のI/Oシ ー
ルドを挿入してから、ケースの中 にマザ
ーボードを取り付けます
将I/O弹片装上机箱,装上主板
5
If you want to use SilverStone NT06-PRO
or other similar CPU cooler, please
relocate the top panel 120mm fan to the
bottom vent near the graphics card area
Falls Sie den SilverStone NT06-PRO
oder einen vergleichbarenCPU-Kühler
verwenden möchten, entfernen Sie bitte
den 120-mm-Lüfter an der oberen
Blende und bringen ihn an den unteren
Belüftungsöffnungen in der Nähe des
Grafikkartenbereichs an
Si vous souhaitez utiliser SilverStone
NT06-PRO ou un autre refroidisseur
de CPU similaire, veuillez déplacer le
ventilateur de 120mm du panneau
supérieur sur la sortie inférieure près
de la zone de la carte graphique
Si quiere usar un SilverStone NT06-PRO
u otro disipador para CPU similar, por favor
recoloque el ventilador de 120mm del panel
frontal en el respiradero inferior cerca de la
zona de la tarjeta gráfica
Se si vuole utilizzare dispersore di calore
CPU SilverStone NT06-PRO o simile,
riposizionare la ventola da 120 mm sulla
presa d’aria inferior vicino alla zona della
scheda video
Если вы собираетесь использовать
SilverStone NT06-PRO или аналогичную
систему охлаждения процессора,
переставьте 120-мм вентилятор с верхней
панели на нижнюю панель с вентиляционными
отверстиями рядом с местом установки
графической картыA
SilverStone NT06-PRO 또는 기타 이와
유사한 CPU 쿨러를 사용하려는 경우 상단
패널의 120mm 팬을 그래픽 카드 근처에
있는 하단 통풍구로 위치를 바꾸십시오
原廠預設安裝兩顆120mm風扇,如果你有使用
NT06-PRO請將上蓋的風扇取下,安裝到顯示卡
區域的後方
SilverStone NT06-PROまたはその 他同様
のCPUクーラーを使用される 場合は、ト
ップパネルの120mmファ ンをグラフィッ
クスカード付近の 底部換気口付近に移動
させます
原厂预设安装两颗120mm风扇,如果你有使用
NT06-PRO请将上盖的风扇取下,安装到显示卡
区域的后方
