Component size limitations
(2) PSU limitation
RVZ03’s maximum depth for a standard PS/2 (ATX) power supply is 150mm, but installation of a 150mm deep power supply will require sacrificing a 2.5"
drive space and no room for cable connection after installation. So if using a 150mm deep modular power supply, make sure to connect all cables prior
to installing it into the case. Power supplies with depth of 140mm or less may have enough room to allow for cable connection after installation so we
recommend using 140mm deep modular power supply with flat cables, such as SilverStone’s own ST75F-PT
Die maximale Tiefe eines standardmäßigen PS/2- (ATX) Netzteils des RVZ03 beträgt 150 mm; allerdings müssen Sie bei Installation eines 150 mm tiefen
Netzteils den Platz eines 2,5-Zoll-Laufwerks opfern und haben nach der Installation keinen Platz mehr zum Anschließen von Kabeln. Achten Sie dabei bei
Verwendung eines 150 mm tiefen modularen Netzteils darauf, dass alle Kabel vor Installation im Gehäuse angeschlossen sind. Netzteile mit einer Tiefe
von 140 mm oder weniger lassen genügend Platz zum Anschließen von Kabeln nach der Installation, weshalb wir ein 140 mm tiefes modulares Netzteil
mit flachen Kabeln empfehlen, wie bspw. SilverStones ST75F-PT
La profondeur maximale du RVZ03 pour un bloc d’alimentation électrique PS/2 (ATX) standard est de 150 mm, mais l'installation d'un bloc d’alimentation
de 150 mm de profondeur nécessite de renoncer à un espace pour disque 2,5" et entraîne l'absence de place pour la connexion des câbles après l'installation.
Par conséquent, en cas d'utilisation d'un bloc d’alimentation électrique modulaire de 150 mm de profondeur, assurez-vous de connecter tous les câbles
avant de l'installer dans le boîtier. Les blocs d’alimentation électrique d'une profondeur de 140 mm ou moins peuvent avoir suffisamment de place pour
permettre la connexion des câbles après l'installation. Nous conseillons donc d'utiliser un bloc d’alimentation modulaire de 140 mm de profondeur avec
des câbles plats, tels que le SilverStone ST75F-PT
La profundidad máxima para una fuente de alimentación PS/2 (ATX) estándar en la RVZ03 es de 150mm, pero la instalación de una fuente de alimentación
con 150mm de profundidad obligará a sacrificar un espacio de dispositivo de 2,5" y no quedará espacio para conectar cables tras la instalación. Por tanto,
si usa una fuente de alimentación modular de 150mm, asegúrese de conectar todos los cables antes de instalarla en la carcasa. Las fuentes de
alimentación con una profundidad de 140mm o menos podrían tener suficiente espacio como para permitir la conexión de cables tras la instalación, por
lo que le recomendamos que use fuentes de alimentación modulares de 140mm de profundidad con cables planos, como la SilverStone ST75F-PT
La profondità massima di RVZ03 per un alimentatore standard PS/2 (ATX) è di 150 mm, ma l'installazione di un alimentatore con profondità di 150 mm
richiede di sacrificare uno spazio per unità da 2,5" e non c'è spazio per il collegamento del cavo dopo l'installazione. Quindi, se si utilizza un alimentatore
modulare con profondità di 150 mm, assicurarsi di collegare tutti i cavi prima di installarlo sul case. Gli alimentatori con profondità di 140 mm o meno
potrebbero avere spazio sufficiente per consentire il collegamento del cavo dopo l'installazione, pertanto si consiglia di utilizzare un alimentatore modulare
con profondità di 140 mm con cavi piatti, come ad esempio ST75F-PT di SilverStone
RVZ03 позволяет устанавливать стандартные блоки питания ATX с глубиной 150 мм, но установка такого блока может препятствовать корректной
установке 2,5-дюймового накопителя и подключению кабелей питания. Поэтому при использовании модульного блока питания глубиной 150 мм
убедитесь, что все нужные кабели подключены до установки его в корпус. Блок питания глубиной 140 мм или менее обеспечивает достаточное
пространство
для подключения кабелей после установки, поэтому мы рекомендуем использовать именно блоки глубиной 140 мм с модульной
конструкцией и плоскими кабелями, например, SilverStone ST75F-PT
RVZ03限定使用長度為150mm以內的標準ATX電源,但當電源長度達150mm時,則無空間可插拔任何模組化線材,中央支架的2.5"硬碟也無法安裝,建議先確認好
需要安裝線材的數量再進行安裝。深度140mm以下則有機會在機殼內插拔模組化線材。因此我們推薦使用140mm以下的模組化扁平線電源,如銀欣ST75F-PT
RVZ03限定使用长度为150mm以内的标准ATX电源,但当电源长度达150mm时,则无空间可插拔任何模块化线材,中央支架的2.5"硬盘也无法安装,建议先确认好
需要安装线材的数量再进行安装。深度140mm以下则有机会在机箱内插拔模块化线材。因此我们推荐使用140mm以下的模块化扁平线电源,如银欣ST75F-PT
표준 PS/2 (ATX) 전원공급장치를 위한 RVZ03의 최대 깊이는 150mm이나, 150mm 깊이의 전원공급장치를 설치하면 2.5" 드라이브 공간을 사용할 수
없게 되고 설치 후 케이블을 연결할 공간이 없어집니다. 따라서 150mm 깊이의 모듈식 전원공급장치를 사용할 경우, 이를 케이스에 설치하기 전에
먼저 모든 케이블을 연결하십시오. 깊이가 140mm 이하인 전원공급장치는 설치 후에도 케이블을 연결할 만큼 공간이 충분할 수 있으므로, SilverStone의
ST75F-PT와 같이 140mm 깊이의 모듈식 전원공급장치를 플랫 케이블과 함께 사용할 것을 권장합니다
RVZ03での標準PS/2 (ATX)電源の最大奥行きは150mmですが、奥行き150mmの電源を装着すると、2.5"ドライブのスペースが犠牲となり、装着後にケーブル接続
の余裕がなくなります。それで、奥行き150mmのモジュラー電源を使用する場合、ケースへの装着前に全てのケーブルを接続しておきます。奥行きが140mm以下で
あれば、装着後もケーブル接続用に十分のスペースがあります。それでフラットケーブル装備の奥行き140mmのモジュラー電源、例えばSilverStone製ST75F-PTを
お勧めいたします
