14
Installation Chart
11
Schließen Sie alle restlichen Kabel an.
Conecte todos los cables restantes.
Collegare tutti i cavi rimanenti.
Connect all remaining cables.
Подключите остальные кабели.
連接所有排線。
连接所有扁平电缆。
남아 있는 모든 케이블을 연결합니다.
残りのケーブルを全て接続します。
Connectez tous les câbles restants.
SUGO Series SG13
