SilverStone SST-SG13B-C [19/30] Connector definition
![SilverStone SST-SG13B-Q [19/30] Connector definition](/views2/1714421/page19/bg13.png)
SUGO Series SG13
21
Connector Definition
Please refer to the motherboard manuals for the motherboard’s “Front Panel Connector ” or “System Panel Connector” pin definition.
Bitte suchen Sie in der Motherboard-Dokumentation nach der Pinbelegung der Anschlüsse des Frontbedienfeldes („Front Panel Connectors“ oder „
System Panel Connectors“).
Veuillez-vous référer au manuel de votre carte mère pour la description des broches "des connecteurs du panneau frontal" et des broches "des connecteurs du panneau
système".
Por favor, consulte en los manuales de la placa base la configuración de pines del “Conector de panel frontal” ó “Conector de panel de sistema” de
su placa base.
Fare riferimento al manuale della scheda madre nella sezione “Connettori del pannello frontale” o “Connettori del pannello di s istema”.
Описание контактов разъемов приведены в разделах “Разъемы передней панели” или “Разъемы системно
й панели” руководства
пользователя материнской платы.
請參考主機說明書的Front Panel Connectors安裝Pin Define,將Connector插上
请参考说明书的Front Panel Connectors安装Pin Define,将Connector插上
메인보드 매뉴얼의 전면패널 커넥터 혹은 시스템패널 커넥터 핀을 참조하기 바랍니다.
マザーボードの「フロントパネルコネクタ」または「システムパネルコネクタ」ピン配列についてはマザーボードマニュアルを参照してください。
B:LED indicators installation guide
(1) Front Panel Connectors
