8
Installation Chart
05
Installieren Sie das 2,5-Zoll-Laufwerk an der Bodenplatte.
Instale el dispositivo de 2,5” en el panel inferior.
Installare l’unità da 2,5” sul pannello inferiore.
Install 2.5” drive onto the bottom panel.
Установите 2,5-дюймовый привод на нижнюю панель.
安裝底板的2.5吋硬碟。
安装底板的2.5吋硬盘。
2.5” 드라이브를 하단 패널에 설치합니다.
2.5"ドライブを底部パネル上にインストールします。
Installez le lecteur 2,5" sur le panneau inférieur.
SUGO Series SG13
