7
Installation Chart
04
Installieren Sie das Motherboard im Gehäuse.
Instale la placa base en el chasis.
Installare la scheda madre nel telaio.
Install motherboard into the chassis.
Установите системную плату в корпус.
將主機板安裝上機殼。
将主板安装上机壳。
메인보드를 섀시에 설치합니다.
ケースにマザーボードを装着します。
Installez la carte mère sur le châssis.
SUGO Series SG13
