![SilverStone SG13 [14/30] Ecr1749 manual sg13 c252 v3 16](/views2/1714421/page14/bge.png)
16
Installation Chart
13
Schließen Sie die Frontblende.
Cierre el panel frontal.
Chiudere il pannello frontale.
Close the front panel.
Закройте лицевую панель.
蓋上前面板。
盖上前面板。
전면 패널을 닫습니다.
フロントパネルを閉じます。
Fermez le panneau frontal.
SUGO Series SG13
