3
3
• VRVII Systems • Outdoor Units
9
• Outdoor Units • VRV COOLING ONLY SYSTEM • RXQ5-10M9W1B
3 Capacity tables
3 - 1 Cooling capacity tables
8HP
NOTES
1 The above table shows the average value of conditions which may occur.
TC: Total capacity: kW ; PI: Power input: kW (Comp. + Outdoor fan motor)
Combination (%) Capacity index
Outdoor air
temp.
CDB
Indoor air temperature: CWB
14,0 16,0 18,0 19,0 20,0 22,0 24,0
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW kW kW
80% 160 10 12.1 1.62 14.4 1.94 16.8 2.28 17.9 2.46 19.1 2.64 21.4 3.01 23.7 3.39
12 12.1 1.65 14.4 1.97 16.8 2.32 17.9 2.50 19.1 2.69 21.4 3.06 23.7 3.45
14 12.1 1.67 14.4 2.01 16.8 2.36 17.9 2.55 19.1 2.74 21.4 3.12 23.7 3.52
16 12.1 1.70 14.4 2.04 16.8 2.41 17.9 2.60 19.1 2.79 21.4 3.18 23.7 3.59
18 12.1 1.73 14.4 2.08 16.8 2.45 17.9 2.65 19.1 2.84 21.4 3.24 23.7 3.66
20 12.1 1.76 14.4 2.12 16.8 2.50 17.9 2.70 19.1 2.90 21.4 3.36 23.7 3.91
21 12.1 1.78 14.4 2.14 16.8 2.53 17.9 2.73 19.1 2.96 21.4 3.48 23.7 4.05
23 12.1 1.81 14.4 2.18 16.8 2.65 17.9 2.90 19.1 3.17 21.4 3.73 23.7 4.35
25 12.1 1.87 14.4 2.32 16.8 2.83 17.9 3.10 19.1 3.39 21.4 3.99 23.7 4.65
27 12.1 1.99 14.4 2.48 16.8 3.02 17.9 3.31 19.1 3.62 21.4 4.27 23.7 4.98
29 12.1 2.11 14.4 2.64 16.8 3.22 17.9 3.53 19.1 3.86 21.4 4.56 23.7 5.32
31 12.1 2.24 14.4 2.80 16.8 3.43 17.9 3.76 19.1 4.11 21.4 4.87 23.4 5.53
33 12.1 2.38 14.4 2.98 16.8 3.65 17.9 4.01 19.1 4.38 21.4 5.19 23.0 5.74
35 12.1 2.53 14.4 3.17 16.8 3.88 17.9 4.26 19.1 4.67 21.4 5.53 22.7 5.94
37 12.1 2.68 14.4 3.36 16.8 4.13 17.9 4.54 19.1 4.97 21.4 5.90 22.3 6.15
39 12.1 2.84 14.4 3.57 16.8 4.39 17.9 4.83 19.1 5.29 21.4 6.28 21.9 6.36
70% 140 10 10.6 1.43 12.6 1.69 14.7 1.97 15.7 2.12 16.7 2.27 18.7 2.58 20.8 2.90
12 10.6 1.45 12.6 1.72 14.7 2.01 15.7 2.16 16.7 2.31 18.7 2.63 20.8 2.96
14 10.6 1.47 12.6 1.75 14.7 2.04 15.7 2.20 16.7 2.36 18.7 2.68 20.8 3.01
16 10.6 1.49 12.6 1.78 14.7 2.08 15.7 2.24 16.7 2.40 18.7 2.73 20.8 3.07
18 10.6 1.52 12.6 1.81 14.7 2.12 15.7 2.28 16.7 2.44 18.7 2.78 20.8 3.13
20 10.6 1.54 12.6 1.84 14.7 2.16 15.7 2.32 16.7 2.49 18.7 2.84 20.8 3.22
21 10.6 1.56 12.6 1.86 14.7 2.18 15.7 2.35 16.7 2.52 18.7 2.88 20.8 3.34
23 10.6 1.58 12.6 1.89 14.7 2.22 15.7 2.43 16.7 2.64 18.7 3.09 20.8 3.57
25 10.6 1.61 12.6 1.97 14.7 2.37 15.7 2.59 16.7 2.82 18.7 3.30 20.8 3.82
27 10.6 1.70 12.6 2.09 14.7 2.53 15.7 2.76 16.7 3.00 18.7 3.52 20.8 4.08
29 10.6 1.81 12.6 2.23 14.7 2.69 15.7 2.94 16.7 3.20 18.7 3.76 20.8 4.36
31 10.6 1.92 12.6 2.37 14.7 2.86 15.7 3.13 16.7 3.41 18.7 4.01 20.8 4.65
33 10.6 2.03 12.6 2.51 14.7 3.04 15.7 3.33 16.7 3.63 18.7 4.27 20.8 4.96
35 10.6 2.15 12.6 2.66 14.7 3.23 15.7 3.54 16.7 3.86 18.7 4.55 20.8 5.29
37 10.6 2.28 12.6 2.83 14.7 3.43 15.7 3.76 16.7 4.11 18.7 4.84 20.8 5.63
39 10.6 2.41 12.6 3.00 14.7 3.65 15.7 4.00 16.7 4.37 18.7 5.15 20.8 6.00
60% 120 10 9.1 1.24 10.8 1.46 12.6 1.68 13.4 1.80 14.3 1.93 16.1 2.18 17.8 2.44
12 9.1 1.26 10.8 1.48 12.6 1.71 13.4 1.83 14.3 1.96 16.1 2.22 17.8 2.48
14 9.1 1.28 10.8 1.50 12.6 1.74 13.4 1.86 14.3 1.99 16.1 2.26 17.8 2.53
16 9.1 1.29 10.8 1.53 12.6 1.77 13.4 1.90 14.3 2.03 16.1 2.30 17.8 2.58
18 9.1 1.31 10.8 1.55 12.6 1.80 13.4 1.93 14.3 2.07 16.1 2.34 17.8 2.63
20 9.1 1.34 10.8 1.58 12.6 1.83 13.4 1.97 14.3 2.10 16.1 2.39 17.8 2.68
21 9.1 1.35 10.8 1.59 12.6 1.85 13.4 1.99 14.3 2.12 16.1 2.41 17.8 2.71
23 9.1 1.37 10.8 1.62 12.6 1.88 13.4 2.02 14.3 2.17 16.1 2.50 17.8 2.88
25 9.1 1.39 10.8 1.65 12.6 1.96 13.4 2.13 14.3 2.30 16.1 2.67 17.8 3.07
27 9.1 1.44 10.8 1.75 12.6 2.08 13.4 2.26 14.3 2.45 16.1 2.85 17.8 3.28
29 9.1 1.53 10.8 1.85 12.6 2.21 13.4 2.41 14.3 2.61 16.1 3.04 17.8 3.50
31 9.1 1.62 10.8 1.97 12.6 2.35 13.4 2.56 14.3 2.78 16.1 3.23 17.8 3.73
33 9.1 1.71 10.8 2.08 12.6 2.50 13.4 2.72 14.3 2.95 16.1 3.44 17.8 3.97
35 9.1 1.81 10.8 2.21 12.6 2.65 13.4 2.89 14.3 3.13 16.1 3.66 17.8 4.23
37 9.1 1.91 10.8 2.34 12.6 2.81 13.4 3.06 14.3 3.33 16.1 3.89 17.8 4.50
39 9.1 2.02 10.8 2.47 12.6 2.98 13.4 3.25 14.3 3.53 16.1 4.13 17.8 4.78
50% 100 10 7.56 1.07 9.0 1.23 10.5 1.41 11.2 1.50 11.9 1.60 13.4 1.80 14.8 2.00
12 7.56 1.08 9.0 1.25 10.5 1.43 11.2 1.53 11.9 1.62 13.4 1.83 14.8 2.03
14 7.56 1.09 9.0 1.27 10.5 1.46 11.2 1.55 11.9 1.65 13.4 1.86 14.8 2.07
16 7.56 1.11 9.0 1.29 10.5 1.48 11.2 1.58 11.9 1.68 13.4 1.89 14.8 2.11
18 7.56 1.12 9.0 1.31 10.5 1.50 11.2 1.60 11.9 1.71 13.4 1.92 14.8 2.15
20 7.56 1.14 9.0 1.33 10.5 1.53 11.2 1.63 11.9 1.74 13.4 1.96 14.8 2.19
21 7.56 1.15 9.0 1.34 10.5 1.54 11.2 1.65 11.9 1.75 13.4 1.98 14.8 2.21
23 7.56 1.17 9.0 1.36 10.5 1.57 11.2 1.68 11.9 1.79 13.4 2.01 14.8 2.26
25 7.56 1.18 9.0 1.38 10.5 1.60 11.2 1.71 11.9 1.84 13.4 2.12 14.8 2.41
27 7.56 1.20 9.0 1.43 10.5 1.68 11.2 1.82 11.9 1.96 13.4 2.25 14.8 2.57
29 7.56 1.27 9.0 1.52 10.5 1.79 11.2 1.93 11.9 2.08 13.4 2.40 14.8 2.74
31 7.56 1.34 9.0 1.61 10.5 1.89 11.2 2.05 11.9 2.21 13.4 2.55 14.8 2.91
33 7.56 1.42 9.0 1.70 10.5 2.01 11.2 2.17 11.9 2.34 13.4 2.70 14.8 3.09
35 7.56 1.50 9.0 1.80 10.5 2.13 11.2 2.30 11.9 2.48 13.4 2.87 14.8 3.29
37 7.56 1.58 9.0 1.90 10.5 2.25 11.2 2.44 11.9 2.63 13.4 3.05 14.8 3.49
39 7.56 1.67 9.0 2.01 10.5 2.38 11.2 2.58 11.9 2.79 13.4 3.23 14.8 3.71
