• Outdoor Units • VRV COOLING ONLY SYSTEM • RXQ5-10M9W1B
3
• VRVII Systems • Outdoor Units
10
3 Capacity tables
3 - 1 Cooling capacity tables
10HP
TC: Total capacity: kW ; PI: Power input: kW (Comp. + Outdoor fan motor)
Combination (%) Capacity index
Outdoor air
temp.
CDB
Indoor air temperature: CWB
14,0 16,0 18,0 19,0 20,0 22,0 24,0
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW kW kW
130% 325 10 24.6 3.69 29.3 4.51 34.0 5.37 35.3 5.48 35.7 5.37 36.6 5.14 37.5 4.91
12 24.6 3.76 29.3 4.60 34.0 5.47 34.8 5.45 35.3 5.34 36.1 5.11 37.0 5.03
14 24.6 3.83 29.3 4.69 33.9 5.54 34.4 5.43 34.8 5.31 35.7 5.27 36.6 5.32
16 24.6 3.90 29.3 4.78 33.5 5.51 33.9 5.47 34.3 5.50 35.2 5.55 36.1 5.60
18 24.6 3.98 29.3 4.87 33.0 5.73 33.4 5.75 33.9 5.78 34.8 5.84 35.7 5.89
20 24.6 4.06 29.3 5.19 32.5 6.00 33.0 6.03 33.4 6.06 34.3 6.12 35.2 6.18
21 24.6 4.17 29.3 5.38 32.3 6.14 32.8 6.17 33.2 6.20 34.1 6.27 35.0 6.33
23 24.6 4.46 29.3 5.77 31.9 6.42 32.3 6.46 32.7 6.49 33.6 6.55 34.5 6.62
25 24.6 4.77 29.3 6.17 31.4 6.70 31.8 6.74 32.3 6.77 33.2 6.84 34.1 6.91
27 24.6 5.10 29.3 6.60 31.0 6.99 31.4 7.02 31.8 7.06 32.7 7.13 33.6 7.21
29 24.6 5.44 29.3 7.06 30.5 7.27 30.9 7.31 31.4 7.35 32.3 7.43 33.2 7.50
31 24.6 5.81 29.2 7.47 30.0 7.55 30.5 7.60 30.9 7.64 31.8 7.72 32.7 7.80
33 24.6 6.19 28.7 7.75 29.6 7.84 30.0 7.88 30.5 7.93 31.4 8.01 32.2 8.10
35 24.6 6.59 28.2 8.04 29.1 8.13 29.6 8.17 30.0 8.22 30.9 8.31 31.8 8.40
37 24.6 7.02 27.8 8.32 28.7 8.42 29.1 8.46 29.6 8.51 30.4 8.61 31.3 8.71
39 24.6 7.47 27.3 8.60 28.2 8.71 28.7 8.76 29.1 8.81 30.0 8.91 30.9 9.01
120% 300 10 22.7 3.37 27.0 4.12 31.4 4.89 33.6 5.29 35.2 5.51 36.0 5.31 36.8 5.10
12 22.7 3.43 27.0 4.19 31.4 4.99 33.6 5.39 34.7 5.48 35.5 5.27 36.3 5.06
14 22.7 3.50 27.0 4.27 31.4 5.08 33.6 5.49 34.2 5.46 35.1 5.24 35.9 5.28
16 22.7 3.56 27.0 4.36 31.4 5.18 33.4 5.53 33.8 5.47 34.6 5.52 35.4 5.56
18 22.7 3.63 27.0 4.44 31.4 5.36 32.9 5.72 33.3 5.75 34.1 5.80 35.0 5.85
20 22.7 3.70 27.0 4.62 31.4 5.76 32.5 6.00 32.9 6.03 33.7 6.08 34.5 6.14
21 22.7 3.74 27.0 4.78 31.4 5.97 32.2 6.14 32.6 6.17 33.5 6.22 34.3 6.28
23 22.7 3.99 27.0 5.13 31.4 6.39 31.8 6.42 32.2 6.45 33.0 6.51 33.8 6.57
25 22.7 4.27 27.0 5.48 30.9 6.67 31.3 6.70 31.7 6.73 32.6 6.79 33.4 6.86
27 22.7 4.56 27.0 5.86 30.5 6.95 30.9 6.98 31.3 7.01 32.1 7.08 32.9 7.15
29 22.7 4.86 27.0 6.26 30.0 7.23 30.4 7.26 30.8 7.30 31.6 7.37 32.5 7.44
31 22.7 5.18 27.0 6.68 29.5 7.51 30.0 7.55 30.4 7.58 31.2 7.66 32.0 7.74
33 22.7 5.52 27.0 7.13 29.1 7.79 29.5 7.83 29.9 7.87 30.7 7.95 31.5 8.03
35 22.7 5.87 27.0 7.60 28.6 8.08 29.0 8.12 29.5 8.16 30.3 8.25 31.1 8.33
37 22.7 6.25 27.0 8.10 28.2 8.36 28.6 8.41 29.0 8.45 29.8 8.54 30.6 8.63
39 22.7 6.65 26.9 8.55 27.7 8.65 28.1 8.70 28.5 8.74 29.4 8.84 30.2 8.93
110% 275 10 20.8 3.06 24.8 3.73 28.8 4.43 30.8 4.78 32.8 5.15 35.3 5.46 36.1 5.27
12 20.8 3.12 24.8 3.80 28.8 4.51 30.8 4.87 32.8 5.24 34.9 5.44 35.6 5.24
14 20.8 3.17 24.8 3.87 28.8 4.60 30.8 4.97 32.8 5.34 34.4 5.41 35.2 5.24
16 20.8 3.23 24.8 3.94 28.8 4.68 30.8 5.06 32.8 5.45 34.0 5.48 34.7 5.52
18 20.8 3.29 24.8 4.02 28.8 4.78 30.8 5.20 32.8 5.71 33.5 5.76 34.3 5.81
20 20.8 3.36 24.8 4.10 28.8 5.06 30.8 5.59 32.3 5.99 33.1 6.04 33.8 6.09
21 20.8 3.39 24.8 4.22 28.8 5.24 30.8 5.79 32.1 6.13 32.8 6.18 33.6 6.23
23 20.8 3.55 24.8 4.52 28.8 5.62 30.8 6.21 31.6 6.41 32.4 6.46 33.1 6.52
25 20.8 3.79 24.8 4.84 28.8 6.02 30.8 6.66 31.2 6.69 31.9 6.75 32.7 6.80
27 20.8 4.04 24.8 5.17 28.8 6.44 30.3 6.94 30.7 6.97 31.5 7.03 32.2 7.09
29 20.8 4.31 24.8 5.52 28.8 6.88 29.9 7.22 30.3 7.25 31.0 7.32 31.8 7.38
31 20.8 4.59 24.8 5.88 28.8 7.34 29.4 7.50 29.8 7.53 30.6 7.60 31.3 7.67
33 20.8 4.88 24.8 6.27 28.6 7.74 29.0 7.78 29.4 7.82 30.1 7.89 30.9 7.97
35 20.8 5.19 24.8 6.68 28.1 8.03 28.5 8.06 28.9 8.10 29.6 8.18 30.4 8.26
37 20.8 5.52 24.8 7.11 27.7 8.31 28.1 8.35 28.4 8.39 29.2 8.47 29.9 8.55
39 20.8 5.87 24.8 7.57 27.2 8.59 27.6 8.64 28.0 8.68 28.7 8.77 29.5 8.85
100% 250 10 18.9 2.76 22.5 3.35 26.2 3.97 28.0 4.28 29.8 4.61 33.5 5.27 35.4 5.45
12 18.9 2.81 22.5 3.41 26.2 4.04 28.0 4.36 29.8 4.69 33.5 5.37 34.9 5.42
14 18.9 2.86 22.5 3.47 26.2 4.12 28.0 4.45 29.8 4.78 33.5 5.47 34.5 5.39
16 18.9 2.91 22.5 3.54 26.2 4.20 28.0 4.53 29.8 4.88 33.3 5.54 34.0 5.48
18 18.9 2.96 22.5 3.61 26.2 4.28 28.0 4.62 29.8 4.98 32.9 5.72 33.6 5.76
20 18.9 3.02 22.5 3.68 26.2 4.41 28.0 4.86 29.8 5.33 32.4 6.00 33.1 6.04
21 18.9 3.05 22.5 3.71 26.2 4.56 28.0 5.03 29.8 5.52 32.2 6.14 32.9 6.18
23 18.9 3.13 22.5 3.96 26.2 4.89 28.0 5.39 29.8 5.92 31.8 6.42 32.4 6.47
25 18.9 3.34 22.5 4.23 26.2 5.23 28.0 5.77 29.8 6.34 31.3 6.70 32.0 6.75
27 18.9 3.56 22.5 4.52 26.2 5.59 28.0 6.17 29.8 6.78 30.8 6.98 31.5 7.03
29 18.9 3.79 22.5 4.82 26.2 5.97 28.0 6.59 29.7 7.20 30.4 7.26 31.1 7.32
31 18.9 4.03 22.5 5.13 26.2 6.37 28.0 7.04 29.3 7.48 29.9 7.54 30.6 7.61
33 18.9 4.29 22.5 5.47 26.2 6.79 28.0 7.51 28.8 7.76 29.5 7.83 30.2 7.90
35 18.9 4.56 22.5 5.82 26.2 7.24 28.0 8.01 28.3 8.05 29.0 8.12 29.7 8.19
37 18.9 4.84 22.5 6.19 26.2 7.71 27.5 8.29 27.9 8.33 28.6 8.40 29.2 8.48
39 18.9 5.14 22.5 6.59 26.2 8.22 27.1 8.58 27.4 8.61 28.1 8.69 28.8 8.77
90% 225 10 17.0 2.47 20.3 2.98 23.6 3.52 25.2 3.80 26.8 4.08 30.1 4.66 33.4 5.25
12 17.0 2.51 20.3 3.03 23.6 3.58 25.2 3.87 26.8 4.16 30.1 4.75 33.4 5.35
14 17.0 2.56 20.3 3.09 23.6 3.65 25.2 3.94 26.8 4.24 30.1 4.84 33.4 5.46
16 17.0 2.60 20.3 3.14 23.6 3.72 25.2 4.02 26.8 4.32 30.1 4.93 33.3 5.54
18 17.0 2.65 20.3 3.20 23.6 3.79 25.2 4.10 26.8 4.40 30.1 5.03 32.9 5.72
20 17.0 2.70 20.3 3.27 23.6 3.87 25.2 4.18 26.8 4.57 30.1 5.41 32.4 6.00
21 17.0 2.72 20.3 3.30 23.6 3.93 25.2 4.32 26.8 4.73 30.1 5.60 32.2 6.14
23 17.0 2.77 20.3 3.43 23.6 4.21 25.2 4.63 26.8 5.07 30.1 6.01 31.7 6.41
25 17.0 2.92 20.3 3.67 23.6 4.50 25.2 4.95 26.8 5.42 30.1 6.43 31.3 6.70
27 17.0 3.11 20.3 3.91 23.6 4.81 25.2 5.29 26.8 5.80 30.1 6.88 30.8 6.98
29 17.0 3.31 20.3 4.17 23.6 5.13 25.2 5.65 26.8 6.19 29.8 7.21 30.4 7.26
31 17.0 3.52 20.3 4.44 23.6 5.47 25.2 6.02 26.8 6.61 29.3 7.49 29.9 7.54
33 17.0 3.74 20.3 4.72 23.6 5.83 25.2 6.42 26.8 7.05 28.9 7.77 29.5 7.83
35 17.0 3.97 20.3 5.02 23.6 6.20 25.2 6.84 26.8 7.51 28.4 8.05 29.0 8.11
37 17.0 4.21 20.3 5.34 23.6 6.60 25.2 7.29 26.8 8.01 27.9 8.34 28.6 8.40
39 17.0 4.47 20.3 5.67 23.6 7.03 25.2 7.76 26.8 8.53 27.5 8.62 28.1 8.69
