• Outdoor Units • VRV COOLING ONLY SYSTEM • RXQ5-10M9W1B
3
• VRVII Systems • Outdoor Units
6
3 Capacity tables
3 - 1 Cooling capacity tables
5HP
TC: Total capacity: kW ; PI: Power input: kW (Comp. + Outdoor fan motor)
Combination (%) Capacity index
Outdoor air
temp.
CDB
Indoor air temperature: CWB
14,0 16,0 18,0 19,0 20,0 22,0 24,0
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW kW kW
130% 162.5 10 12.3 1.91 14.6 2.33 17.0 2.78 17.6 2.83 17.9 2.78 18.3 2.66 18.7 2.54
12 12.3 1.94 14.6 2.38 17.0 2.83 17.4 2.82 17.6 2.76 18.1 2.64 18.5 2.60
14 12.3 1.98 14.6 2.42 17.0 2.86 17.2 2.80 17.4 2.74 17.8 2.72 18.3 2.75
16 12.3 2.02 14.6 2.47 16.7 2.85 16.9 2.83 17.2 2.84 17.6 2.87 18.1 2.90
18 12.3 2.06 14.6 2.52 16.5 2.96 16.7 2.97 16.9 2.99 17.4 3.02 17.8 3.05
20 12.3 2.10 14.6 2.68 16.3 3.10 16.5 3.12 16.7 3.13 17.2 3.16 17.6 3.20
21 12.3 2.16 14.6 2.78 16.2 3.18 16.4 3.19 16.6 3.21 17.0 3.24 17.5 3.27
23 12.3 2.31 14.6 2.98 15.9 3.32 16.2 3.34 16.4 3.35 16.8 3.39 17.3 3.42
25 12.3 2.47 14.6 3.19 15.7 3.47 15.9 3.48 16.1 3.50 16.6 3.54 17.0 3.57
27 12.3 2.64 14.6 3.41 15.5 3.61 15.7 3.63 15.9 3.65 16.4 3.69 16.8 3.73
29 12.3 2.81 14.6 3.65 15.2 3.76 15.5 3.78 15.7 3.80 16.1 3.84 16.6 3.88
31 12.3 3.00 14.6 3.86 15.0 3.90 15.2 3.93 15.5 3.95 15.9 3.99 16.3 4.03
33 12.3 3.20 14.3 4.01 14.8 4.05 15.0 4.07 15.2 4.10 15.7 4.14 16.1 4.19
35 12.3 3.41 14.1 4.15 14.6 4.20 14.8 4.22 15.0 4.25 15.5 4.30 15.9 4.34
37 12.3 3.63 13.9 4.30 14.3 4.35 14.6 4.37 14.8 4.40 15.2 4.45 15.7 4.50
39 12.3 3.86 13.7 4.45 14.1 4.50 14.3 4.53 14.6 4.55 15.0 4.61 15.4 4.66
120% 150 10 11.3 1.74 13.5 2.13 15.7 2.53 16.8 2.73 17.6 2.85 18.0 2.74 18.4 2.63
12 11.3 1.77 13.5 2.17 15.7 2.58 16.8 2.79 17.3 2.83 17.8 2.73 18.2 2.62
14 11.3 1.81 13.5 2.21 15.7 2.63 16.8 2.84 17.1 2.82 17.5 2.71 17.9 2.73
16 11.3 1.84 13.5 2.25 15.7 2.68 16.7 2.86 16.9 2.83 17.3 2.85 17.7 2.88
18 11.3 1.88 13.5 2.30 15.7 2.77 16.5 2.96 16.7 2.97 17.1 3.00 17.5 3.02
20 11.3 1.91 13.5 2.39 15.7 2.98 16.2 3.10 16.4 3.11 16.8 3.14 17.3 3.17
21 11.3 1.93 13.5 2.47 15.7 3.09 16.1 3.17 16.3 3.19 16.7 3.22 17.1 3.25
23 11.3 2.06 13.5 2.65 15.7 3.30 15.9 3.32 16.1 3.33 16.5 3.36 16.9 3.40
25 11.3 2.21 13.5 2.83 15.5 3.45 15.7 3.46 15.9 3.48 16.3 3.51 16.7 3.54
27 11.3 2.35 13.5 3.03 15.2 3.59 15.4 3.61 15.6 3.63 16.0 3.66 16.5 3.70
29 11.3 2.51 13.5 3.24 15.0 3.74 15.2 3.75 15.4 3.77 15.8 3.81 16.2 3.85
31 11.3 2.68 13.5 3.45 14.8 3.88 15.0 3.90 15.2 3.92 15.6 3.96 16.0 4.00
33 11.3 2.85 13.5 3.69 14.5 4.03 14.8 4.05 15.0 4.07 15.4 4.11 15.8 4.15
35 11.3 3.03 13.5 3.93 14.3 4.17 14.5 4.20 14.7 4.22 15.1 4.26 15.5 4.31
37 11.3 3.23 13.5 4.19 14.1 4.32 14.3 4.35 14.5 4.37 14.9 4.41 15.3 4.46
39 11.3 3.44 13.5 4.42 13.9 4.47 14.1 4.49 14.3 4.52 14.7 4.57 15.1 4.62
110% 137.5 10 10.4 1.58 12.4 1.93 14.4 2.29 15.4 2.47 16.4 2.66 17.7 2.82 18.0 2.73
12 10.4 1.61 12.4 1.96 14.4 2.33 15.4 2.52 16.4 2.71 17.4 2.81 17.8 2.71
14 10.4 1.64 12.4 2.00 14.4 2.38 15.4 2.57 16.4 2.76 17.2 2.79 17.6 2.71
16 10.4 1.67 12.4 2.04 14.4 2.42 15.4 2.62 16.4 2.82 17.0 2.83 17.4 2.85
18 10.4 1.70 12.4 2.08 14.4 2.47 15.4 2.69 16.4 2.95 16.8 2.98 17.1 3.00
20 10.4 1.73 12.4 2.12 14.4 2.62 15.4 2.89 16.2 3.09 16.5 3.12 16.9 3.15
21 10.4 1.75 12.4 2.18 14.4 2.71 15.4 2.99 16.0 3.17 16.4 3.19 16.8 3.22
23 10.4 1.83 12.4 2.34 14.4 2.90 15.4 3.21 15.8 3.31 16.2 3.34 16.6 3.37
25 10.4 1.96 12.4 2.50 14.4 3.11 15.4 3.44 15.6 3.46 16.0 3.49 16.3 3.52
27 10.4 2.09 12.4 2.67 14.4 3.33 15.2 3.59 15.4 3.60 15.7 3.63 16.1 3.67
29 10.4 2.23 12.4 2.85 14.4 3.55 14.9 3.73 15.1 3.75 15.5 3.78 15.9 3.82
31 10.4 2.37 12.4 3.04 14.4 3.80 14.7 3.88 14.9 3.89 15.3 3.93 15.7 3.97
33 10.4 2.52 12.4 3.24 14.3 4.00 14.5 4.02 14.7 4.04 15.1 4.08 15.4 4.12
35 10.4 2.68 12.4 3.45 14.1 4.15 14.3 4.17 14.4 4.19 14.8 4.23 15.2 4.27
37 10.4 2.85 12.4 3.68 13.8 4.29 14.0 4.32 14.2 4.34 14.6 4.38 15.0 4.42
39 10.4 3.03 12.4 3.92 13.6 4.44 13.8 4.46 14.0 4.49 14.4 4.53 14.7 4.58
100% 125 10 9.45 1.43 11.3 1.73 13.1 2.05 14.0 2.21 14.9 2.38 16.7 2.72 17.7 2.82
12 9.45 1.45 11.3 1.76 13.1 2.09 14.0 2.26 14.9 2.43 16.7 2.77 17.5 2.80
14 9.45 1.48 11.3 1.79 13.1 2.13 14.0 2.30 14.9 2.47 16.7 2.83 17.2 2.79
16 9.45 1.50 11.3 1.83 13.1 2.17 14.0 2.34 14.9 2.52 16.7 2.86 17.0 2.83
18 9.45 1.53 11.3 1.86 13.1 2.21 14.0 2.39 14.9 2.57 16.4 2.96 16.8 2.98
20 9.45 1.56 11.3 1.90 13.1 2.28 14.0 2.51 14.9 2.75 16.2 3.10 16.6 3.12
21 9.45 1.58 11.3 1.92 13.1 2.36 14.0 2.60 14.9 2.85 16.1 3.17 16.4 3.20
23 9.45 1.62 11.3 2.05 13.1 2.53 14.0 2.79 14.9 3.06 15.9 3.32 16.2 3.34
25 9.45 1.73 11.3 2.19 13.1 2.70 14.0 2.98 14.9 3.28 15.6 3.46 16.0 3.49
27 9.45 1.84 11.3 2.33 13.1 2.89 14.0 3.19 14.9 3.51 15.4 3.61 15.8 3.64
29 9.45 1.96 11.3 2.49 13.1 3.09 14.0 3.41 14.9 3.72 15.2 3.75 15.5 3.78
31 9.45 2.09 11.3 2.65 13.1 3.29 14.0 3.64 14.6 3.87 15.0 3.90 15.3 3.93
33 9.45 2.22 11.3 2.83 13.1 3.51 14.0 3.88 14.4 4.01 14.7 4.05 15.1 4.08
35 9.45 2.36 11.3 3.01 13.1 3.74 14.0 4.14 14.2 4.16 14.5 4.19 14.9 4.23
37 9.45 2.50 11.3 3.20 13.1 3.99 13.8 4.29 13.9 4.31 14.3 4.34 14.6 4.38
39 9.45 2.66 11.3 3.41 13.1 4.25 13.5 4.43 13.7 4.45 14.1 4.49 14.4 4.53
90% 112.5 10 8.50 1.28 10.1 1.54 11.8 1.82 12.6 1.96 13.4 2.11 15.1 2.41 16.7 2.72
12 8.50 1.30 10.1 1.57 11.8 1.85 12.6 2.00 13.4 2.15 15.1 2.45 16.7 2.77
14 8.50 1.32 10.1 1.60 11.8 1.89 12.6 2.04 13.4 2.19 15.1 2.50 16.7 2.82
16 8.50 1.34 10.1 1.63 11.8 1.92 12.6 2.08 13.4 2.23 15.1 2.55 16.7 2.87
18 8.50 1.37 10.1 1.66 11.8 1.96 12.6 2.12 13.4 2.28 15.1 2.60 16.4 2.96
20 8.50 1.39 10.1 1.69 11.8 2.00 12.6 2.16 13.4 2.36 15.1 2.80 16.2 3.10
21 8.50 1.41 10.1 1.70 11.8 2.03 12.6 2.23 13.4 2.45 15.1 2.90 16.1 3.17
23 8.50 1.43 10.1 1.78 11.8 2.18 12.6 2.39 13.4 2.62 15.1 3.11 15.9 3.32
25 8.50 1.51 10.1 1.90 11.8 2.33 12.6 2.56 13.4 2.80 15.1 3.33 15.6 3.46
27 8.50 1.61 10.1 2.02 11.8 2.48 12.6 2.73 13.4 3.00 15.1 3.56 15.4 3.61
29 8.50 1.71 10.1 2.15 11.8 2.65 12.6 2.92 13.4 3.20 14.9 3.72 15.2 3.75
31 8.50 1.82 10.1 2.29 11.8 2.83 12.6 3.11 13.4 3.42 14.7 3.87 15.0 3.90
33 8.50 1.93 10.1 2.44 11.8 3.01 12.6 3.32 13.4 3.64 14.4 4.01 14.7 4.05
35 8.50 2.05 10.1 2.60 11.8 3.21 12.6 3.54 13.4 3.88 14.2 4.16 14.5 4.19
37 8.50 2.18 10.1 2.76 11.8 3.41 12.6 3.77 13.4 4.14 14.0 4.31 14.3 4.34
39 8.50 2.31 10.1 2.93 11.8 3.63 12.6 4.01 13.4 4.41 13.7 4.46 14.0 4.49
