Daikin RXQ5M9W1B [5/32] 2 electrical specifications

• Outdoor Units • VRV COOLING ONLY SYSTEM • RXQ5-10M9W1B

• VRVII Systems • Outdoor Units

1-2 ELECTRICAL SPECIFICATIONS RXQ5M9W1B RXQ8M9W1B RXQ10M9W1B

Power Supply Name W1

Phase 3N

Frequency Hz 50 50 50

Voltage V 400 400 400

Current Nominal running

current (RLA)

Cooling A 6.50 12.00 12.60

Starting current (MSC) A 15.00 71.00 71.00

Minimum circuit amps (MCA) A 12.00 19.50 22.40

Maximum fuse amps (MFA) A 16.00 32.00 32.00

Total overcurrent amps

(TOCA)

A 14.40 29.80 29.80

Full load amps (FLA) A 0.3 (fan motor) 0.7 (fan motor) 0.7 (fan motor)

Voltage range Minimum V 360 360 360

Maximum V 440 440 440

Wiring

connections

For Power

Supply

Quantity 5 5 5

Remark earth wire include

For connection

with indoor

Quantity 2 2 2

Remark P1 - P2

Power Supply Intake Both indoor and outdoor unit

Notes MCA/MFA : MCA = 1.25 x maximum RLA + other RLA + EA FLA, MCA<= 2.25 x maximum RLA + other RLA + EA FLA,

next lower standard fuse rating minimum 16A

MFA is used to select the circuit breaker and the ground fault circuit interrupter (earth leakage circuit breaker)

MSC means the maximum current during start up of the compressor

Maximum allowable voltage range variation between phases is 2%

RLA is based on following conditions : indoor temperature : 270CDB/190CWB , outdoor temperature : 350CDB

Select wire size based on the value of MCA or TOCA

TOCA means the total value of each OC set

Voltage range : units are suitable for use on electrical systems where voltage supplied to unit terminal is not below or

above listed range limits

For more details concerning conditional connections, see

http://www.daikineurope.com/extranet, select "Daikin Documentation" and select "conditional connection", "the

requested product type" and "English" from the drop down lists, click the search button.

Finally, click on the document title of your choice.
