Heat Pump / Cooling Only 50Hz (RX(Y)Q5~54P) SiEN34-705
218 Installation Manual
3.2 Introduction
! RX(Y)Q-P series are designed for outdoor installation and used for cooling and heatpump
(except RXQ-P) applications. Outdoor units come in three standard sizes, and with a single
system through a multi system combining up to three outdoor units, rated cooling capacity
from 14.0 kW to 147 kW and rated heating capacity from 16.0 kW to 170 kW (except RXQ-P)
can be achieved.
! The RX(Y)Q-P units can be combined with Daikin VRV series indoor units for air
conditioning purposes. Always use appropriate indoor units compatible with R-410A. To lean
which models of indoor units are compatible with R-410A, refer to the product catalogs.
To combine with other refrigerant indoor unit will cause malfunction.
3.2.1 Combination
The indoor units can be installed in the following range.
(The total number of indoor units cannot exceed 64 units.)
<Outdoor unit> <Total capacity of indoor units> <Total quantity of indoor units>
RX(Y)Q5PY1...................... 62.5 ~ 250 12 units
RX(Y)Q8PY1.................... 100 ~ 400 20 units
RX(Y)Q10PY1................. 125 ~ 500 25 units
RX(Y)Q12PY1.................. 150 ~ 600 30 units
RX(Y)Q14PY1.................. 175 ~ 700 35 units
RX(Y)Q16PY1.................. 200 ~ 800 40 units
RX(Y)Q18PY1.................. 225 ~ 900 45 units
RX(Y)Q20PY1.................. 250 ~ 800 40 units
RX(Y)Q22PY1.................. 275 ~ 880 44 units
RX(Y)Q24PY1.................. 300 ~ 960 48 units
RX(Y)Q26PY1.................. 325 ~ 1040 52 units
RX(Y)Q28PY1.................. 350 ~ 1120 56 units
RX(Y)Q30PY1.................. 375 ~ 1200 60 units
RX(Y)Q32PY1.................. 400 ~ 1280 64 units
RX(Y)Q34PY1.................. 425 ~ 1360 64 units
RX(Y)Q36PY1.................. 450 ~ 1440 64 units
RX(Y)Q38PY1.................. 475 ~ 1235 61 units
RX(Y)Q40PY1.................. 500 ~ 1300 64 units
RX(Y)Q42PY1.................. 525 ~ 1365 64 units
RX(Y)Q44PY1.................. 550 ~ 1430 64 units
RX(Y)Q46PY1.................. 575 ~ 1495 64 units
RX(Y)Q48PY1.................. 600 ~ 1560 64 units
RX(Y)Q50PY1.................. 625 ~ 1625 64 units
RX(Y)Q52PY1.................. 650 ~ 1690 64 units
RX(Y)Q54PY1.................. 675 ~ 1755 64 units
Note: ! Be sure to connect an R-410A indoor unit.
See the catalog for indoor unit models which can be connected.
! At above is the total capacity and total number of units of the indoor units when configured in
a standard combination. See the technical reference for details on total capacity and total
number of indoor units when using a configuration other than the standard combination. The
standard combination are as follows.
