Planet IAD-200W [10/111] Package contents

Package Contents

The following items should be included. If any of these items are damaged or missing, please

contact your dealer immediately.

• The IAD-200 / IAD-200W Unit

• 1 Cat-5 Ethernet (LAN) cable

• 1 RJ-11 (ADSL) cable

• Power Adapter

• Quick Installation Guide

• CD-ROM containing the on-line manual.
