Planet IAD-200W [30/111] Password screen

Password Screen

The password screen allows you to assign a password to the IAD-200 / IAD-200W.

Figure 11: Password Screen

Old Password

Enter the existing password in this field.

New password

Enter the new password here.

Verify password

Re-enter the new password here.

You will be prompted for the password when you connect, as shown below.

Figure 12: Password Dialog

• The "User Name" is always admin

• Enter the password for the IAD-200 / IAD-200W, as set on the Password screen above.
