IP DSLAM
155
CRC Errors count
This specifies the number of CRC errors encountered.
Oversized SDU
This specifies the number of oversized SDUs received.
References:
z atm vc related commands
z atm port and statistics related commands
z atm vc statistics commands.
5.5.2 ATM OAM CC Commands
5.5.2.1 Get oam cc vc
Description:
Use this command to get.
Command Syntax:
get oam cc vc [ifname <interface-name>]
5.5.2.2 Modify oam cc vc
Description:
Use this command to modify.
Command Syntax:
modify oam cc vc ifname <interface-name> [action act | deact] [dir sink | src |
both] [mode auto | manual]
Parameters:
Name Description
ifname
<interface-name>
This parameter specifies the interface, for which information is desired.
In case the field is not specified, then the information for all valid
interfaces should be displayed.
Type: Modify -- Mandatory
Get -- Optional
action act | deact
This field specifies the CC action to be taken. This is used along with
CC direction field.
Type: Modify -- Optional
dir sink | src | both
This field specifies the direction for CC
activation/Deactivation.Direction could be source (src), sink or both.
