IDL series User Guide
226
Type: Modify -- Optional
aturthreshintlrateup
<aturthreshintlrateup-val>
Applies to 'Interleave' channels only. Configured change in rate
causing an adslAturRateChangeTrap A trap is produced when:
ChanCurrTxRate > ChanPrevTxRate plus the value of this object.
Type: Modify -- Optional
aturthreshfastratedn
<aturthreshfastratedn-val>
Applies to 'Fast' channels only. Configured change in rate causing
an adslAturRateChangeTrap A trap is produced when:
ChanCurrTxRate < ChanPrevTxRate minus the value of this object.
Type: Modify -- Optional
aturthreshintlratedn
<aturthreshintlratedn-val>
Applies to 'Interleave' channels only. Configured change in rate
causing an adslAturRateChangeTrap A trap is produced when:
ChanCurrTxRate < ChanPrevTxRate minus the value of this object.
Type: Modify -- Optional
atucgspmstatetrapenable
False | True
This indicates change in power mangement state
Type: Modify -- Optional
Valid values: False, True
linealarmgscntrsreset False
| True
This parameter resets performance counters at runtime
Type: Modify -- Optional
Valid values: False, True
Example:
$ get adsl alarm profile ifname dsl-0
Output:
IfName : dsl-0
ADSL ATUC Configuration :
------------------------------
Thresh 15Min Lofs(sec) : 10 Thresh 15Min Loss(sec) : 20
Thresh 15Min Lols(sec) : 30 Thresh 15Min Lprs(sec) : 50
Thresh 15Min Ess(sec) : 40 Thresh Fast Rate Up(bps): 70
Thresh Intl Rate Up(bps) : 30 Thresh Fast Rate Down(bps):10
Thresh Intl Rate Down(bps) : 30 Init Fail Trap : true
OpStateTrapEnable : false PowerMgmtTrapEnable : True
ADSL ATUR Configuration :
------------------------------
Thresh 15Min Lofs(sec) : 10
Thresh 15Min Loss(sec) : 10 Thresh 15Min Lprs(sec) : 10
Thresh 15Min Ess(sec) : 10 Thresh Fast Rate Up(bps: 10
Thresh Intl Rate Up(bps) : 10 Thresh Fast Rate Down(bps):10
Thresh Intl Rate Down(bps) : 10
