IDL series User Guide
628
DnLink Learn Entry Discards : 30 NET Learn Entry Discards : 100
Dyn Addr Conflicts Static : 40 Moved Dyn Addrs Count : 110
Ucast Lookup Fail Count : 50 Mcast Lookup Fail Count : 120
Tx Ctl Pkts Count : 60 Rx Ctl Pkts Count : 130
Ctl Pkts Discards Count : 70
PPPOE Session Look Up Failures: 5
Output Fields:
FIELD Description
CPE Ucast Addr
Count
Number of unicast addresses, which were learned from the
CPE ports.
DnLink Ucast Addr
Count
Number of unicast addresse,s which were learned from the
Downlink port.
Learn Entry Discards
Number of addresses which, were not learned from the
CPE ports, due to lack of space in the forwarding table.
DnLink Learn Entry
Discards
Number of addresses which, were not learned from the
Downlink port, due to lack of space in the for-warding
table.
Dyn Addr Conflicts
Static
Number of times a learned address conflicted with a static
address.
Moved Dyn Addrs
Count
Number of times a learned address moved from one port
to another.
Ucast Lookup Fail
Count
Number of times Unicast address lookup failed.
Mcast Lookup Fail
Count
Number of times Multicast address lookup failed.
Tx Ctl Pkts Count
Number of packets sent to the Control module.
Rx Ctl Pkts Count
Number of packets received from Control module.
Ctl Pkts Discards
Count
Number Control module packets discarded.
NumNetUcastAddrCo
unt
Number of unicast addresses which were learned from the
Net ports.
NumNetLearnEntryDi
scards
Number of addresses, which were not learned from the
Net ports, due to lack of space in the forwarding table.
