IDL series User Guide
26
1.4 Outlook
IDL-2400
IDL-4800
IDL-2401 / IDL-4801 with 1000Base-LX UPLINK
1 x 1000Base-LX UPLINK1
1 x 1000Base-T UPLINK2
1 x 1000Base-T MGNT
