![Planet IDL-4801 [582/707] Snmp commands](/views2/1071613/page582/bg246.png)
IDL series User Guide
582
5.23 SNMP Commands
5.23.1 SNMP Comm Commands
5.23.1.1 Get snmp comm
Description:
Use this command to get.
Command Syntax:
get snmp comm [community <community-val >]
5.23.1.2 Create snmp comm
Description:
Use this command to create.
Command Syntax:
create snmp comm community <community-val > [access ro | rw]
5.23.1.3 Delete snmp comm
Description:
Use this command to delete.
Command Syntax:
delete snmp comm community <community-val>
Parameter:
Name Description
community
<community-val >
This specifies the Community name.
Type: Create － Mandatory
Delete － Mandatory
Get － Optional
access ro | rw
This specifies the access permissions given to
man-agers with this community name. ro implies
Read Only permissions and rw implies Read-Write
per-missions.
Type: Create － Optional
Default value: ro
