IP DSLAM
499
5.19.3 PPPoE Global Serviceprofile Commands
5.19.3.1 Get pppoe global serviceprofile
Description:
Use this command to get.
Command Syntax:
get pppoe global serviceprofile [profileid <profileid-val>]
5.19.3.2 Create pppoe global serviceprofile
Description:
Use this command to create.
Command Syntax:
create pppoe global serviceprofile profileid <profileid-val> servicename
<servicename-val>
5.19.3.3 Delete pppoe global serviceprofile
Description:
Use this command to delete.
Command Syntax:
delete pppoe global serviceprofile profileid <profileid-val>
Parameters:
Name Description
profileid <profileid-val>
Profile Id of the Service Name configured.
Type: Create － Mandatory
Delete － Mandatory
Get － Optional
Valid values: 1 -4
servicename
<servicename-val>
Service Name for the Session, based on which,
the AC is selected.
Type: Create － Mandatory
Example:
$ create pppoe global serviceprofile profileid 1 servicename any
